/Vibro-Meter CA202 144-202-000-206 Piezoelectric Accelerometer

Vibro-Meter CA202 144-202-000-206 Piezoelectric Accelerometer

Vibro-Meter CA202 144-202-000-206

CA202 144-202-000-206

The CA202 144-202-000-206 is a Meggitt Vibro-Meter piezoelectric accelerometer with insulated charge output and a 3 m integral cable for high-temperature machinery vibration measurement.

MODULE TYPECA202 piezoelectric accelerometer

SYSTEM FAMILYCA202 piezoelectric accelerometer family

COMPATIBILITY3 m integral cable · insulated charge output

ORDERING NUMBER144-202-000-206

MANUFACTURERMeggitt vibro-meter

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

VIBRO-METER ● CA202 PIEZOELECTRIC ACCELEROMETER

Vibro-Meter CA202

CA202 144-202-000-206

144-202-000-206 · COMPLETE ORDERING REFERENCE

High-temperature piezoelectric vibration measurement

MODULE ROLE

CA202 144-202-000-206 is a Meggitt Vibro-Meter piezoelectric accelerometer with insulated charge output and a 3 m integral cable for machinery vibration measurement.

CONFIGURATION NOTE

For CA202 144-202-000-206, confirm the complete nameplate reference, 3 m integral cable, 100 pC/g sensitivity, measuring range, frequency range, mounting and matching charge-input instrumentation before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Meggitt Vibro-Meter ↗

CA202 PIEZOELECTRIC ACCELEROMETER

Engineering data at a glance

Click “+” to expand more specifications.

MODULE TYPECA202 piezoelectric accelerometer

SENSITIVITY100 pC/g ±5%

FREQUENCY RANGE0.5 to 6000 Hz

OUTPUTInsulated charge

Official Vibro-Meter CA202 data sheet DS 263-133 identifies 144-202-000-206 as the standard version with a 3 m integral cable.

Accelerometer ConfigurationCA202 144-202-000-206 is the standard CA202 version with a 3 m integral cable, 100 pC/g nominal sensitivity and insulated charge output.

GENERAL INFORMATION−

Brand / product lineMeggitt Vibro-Meter

Ordering numberCA202 144-202-000-206

Product typeVibro-Meter CA202 piezoelectric accelerometer

Ordering versionStandard version with 3 m integral cable

Electrical output2-pin insulated charge output

Nominal sensitivity100 pC/g ±5%

Measuring range0.01 to 400 g

Frequency range0.5 to 6000 Hz ±5%

Sensor temperature−55 to +260 °C

Cable temperature−55 to +200 °C

Construction and Connection＋

Integral cable3 m for ordering number 144-202-000-206

ConstructionStainless-steel, leaktight sensor assembly

Sensor massApproximately 250 g

Mechanical and Installation Characteristics＋

Cable massApproximately 135 g/m

MountingFour M6 bolts, 15 Nm tightening torque

Output connectionIntegral cable with 2-pin insulated charge output

Environmental sealingLeaktight welded stainless-steel assembly

Ordering reference144-202-000-206 standard 3 m cable version

Installation and Replacement Check＋

Confirm the full 144-202-000-206 nameplate, integral cable length, mounting surface, bolt torque, charge-input compatibility and operating temperature before installation or replacement.

FAQ

Questions Buyers Ask Most

What is CA202 144-202-000-206?＋

CA202 144-202-000-206 is the standard Vibro-Meter CA202 piezoelectric accelerometer version with a 3 m integral cable and insulated charge output.

What output does CA202 144-202-000-206 provide?＋

CA202 144-202-000-206 provides a 2-pin insulated charge output for compatible charge-input instrumentation.

What cable is supplied with CA202 144-202-000-206?＋

CA202 144-202-000-206 is the standard version supplied with a 3 m integral cable.

What sensitivity is specified for CA202 144-202-000-206?＋

CA202 144-202-000-206 has a nominal charge sensitivity of 100 pC/g with a ±5% tolerance.

What measuring and frequency ranges apply to CA202 144-202-000-206?＋

CA202 144-202-000-206 is specified for 0.01 to 400 g and 0.5 to 6000 Hz at ±5%.

What temperature range applies to CA202 144-202-000-206?＋

CA202 144-202-000-206 supports −55 to +260 °C at the sensor; the integral cable is specified for −55 to +200 °C.

What should be checked before replacing CA202 144-202-000-206?＋

CA202 144-202-000-206 should be checked by complete PNR, 3 m cable, sensitivity, frequency range, temperature limits, mounting and charge-input compatibility.

CONTACT PRODUCT SPECIALIST

Check your CA202 configuration with Frida

Share the complete CA202 PNR, cable length, mounting details, operating temperature and charge-input requirements for compatibility checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Product Information for
CA202 144-202-000-206

The official Meggitt Vibro-Meter CA202 data sheet covers the CA202 piezoelectric accelerometer family and identifies 144-202-000-206 as the standard version with a 3 m integral cable.

Official datasheet status

The official manufacturer-hosted CA202 data sheet provides ordering information, sensitivity, measuring range, frequency response, temperature limits, mounting and dimensional data for CA202 variants.

OPEN OFFICIAL DATASHEET PDF

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Open the official CA202 data sheet and confirm the full 144-202-000-206 nameplate reference, 3 m cable, sensitivity, frequency range, temperature limits and mounting before replacement.

CA202 SENSOR IDENTITY

How CA202 144-202-000-206 Fits the Vibro-Meter Vibration Measurement System

Meggitt Vibro-Meter is the product line; CA202 identifies the piezoelectric accelerometer family; and CA202 144-202-000-206 is the standard 3 m integral-cable version.

Meggitt Vibro-Meter · PRODUCT LINE

CA202 piezoelectric accelerometer with charge-input instrumentationPIEZOELECTRIC SENSOR · CHARGE-OUTPUT RELATIONSHIP

ACCELEROMETER MODEL

CA202 · 144-202-000-206

The CA202 accelerometer converts machinery vibration into an insulated charge output for compatible charge-input instrumentation.

SENSOR FAMILY

CA202 piezoelectric accelerometer

The measurement chain uses the CA202 sensor, its 3 m integral cable and compatible charge-input monitoring instrumentation.

ACCELEROMETER CHARACTERISTICS

100 pC/g · 0.01 to 400 g · 0.5 to 6000 Hz

Ordering number 144-202-000-206 identifies the standard CA202 version with a 3 m integral cable and insulated charge output.

Compatibility check: match the complete 144-202-000-206 PNR, 3 m integral cable, 100 pC/g sensitivity, mounting, temperature limits and charge-input instrumentation before replacement.

APPLICATION AREAS

Application map for CA202 144-202-000-206

High-Temperature Machinery VibrationMeasures vibration where the sensor body can operate up to +260 °C

Bearing and Casing VibrationProvides charge-output vibration measurement on machinery housings

APPLICATION CENTERCA202 144-202-000-206Vibro-Meter piezoelectric accelerometer with 3 m integral cable

Wide Frequency MeasurementCovers 0.5 to 6000 Hz with 100 pC/g nominal sensitivity

Industrial MountingUses four M6 mounting bolts tightened to 15 Nm
