Bently Nevada 9200-01-02-02-00 Seismoprobe Velocity Transducer

TWO-WIRE · VELOCITY

9200-01-02-02-00

9200-01-02-02-00 — A two-wire moving-coil velocity transducer for continuous or periodic absolute bearing-housing, casing and structural vibration measurement.

TYPETwo-wire

FREQUENCY4.5–1000 Hz

MOUNTING BASE1/4-28 UNF

CONNECTORSide mount

MANUFACTURERBently Nevada · Baker Hughes

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

BENTLY NEVADA ● 9200 SEISMOPROBE

SEISMOPROBE VELOCITY TRANSDUCER

9200-01-02-02-00

4.5–1000 Hz · 1/4-28 UNF base · Side mount

Seismoprobe Velocity Transducer

MEASUREMENT ROLE

9200-01-02-02-00 — A two-wire moving-coil transducer for continuous or periodic absolute bearing-housing, casing and structural vibration measurement.

CONFIGURATION NOTE

01 = 0° mounting orientation with 4.5 Hz minimum operating frequency; first 02 = side-mount connector with no cable; second 02 = circular base with 1/4-28 UNF stud; 00 = no agency approvals.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

CONFIGURATION DECODING

Model code at a glance

9200

Base modeltwo-wire moving-coil Seismoprobe

Orientation / frequency0° · 4.5 Hz minimum

ConnectorSide mount · no cable

Mounting baseCircular · 1/4-28 UNF

ApprovalNo approvals

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

9200 / 74712 Official PDF ↗

9200 SEISMOPROBE

Engineering data at a glance

Click “+” to expand more specifications.

TYPETwo-wire

FREQUENCY4.5–1000 Hz

MOUNTING BASE1/4-28 UNF

CONNECTORSide mount

Configuration from manufacturer ordering data.

Configuration check Confirm mounting orientation, 4.5 Hz minimum frequency, side-mount connector, circular 1/4-28 UNF base, environment and monitor input before ordering.

General Information −

BrandBently Nevada

Part number9200-01-02-02-00

Product typetwo-wire velocity transducer

Product family9200 Seismoprobe

Measurement principleMoving-coil · two-wire

OutputVelocity-proportional voltage

Detailed Measurement Data ＋

Sensitivity20 mV/mm/s (500 mV/in/s) ±5%

Frequency response4.5 to 1000 Hz (+0, -3 dB typical)

Coil resistance1.25 kΩ ±5%

Cable and Installation ＋

Mounting orientation0° mounting orientation

Minimum operating frequency4.5 Hz

Mounting baseCircular base · 1/4-28 UNF stud

Connector optionSide mount · no cable

Agency approvalOption 00 · no approvals

Environment and Documentation ＋

Operating and storage temperature: -29°C to +121°C. Confirm orientation, cable, load, installation surface and monitoring input for the exact application.

Source: Bently Nevada 141626 Rev. V. System values require the complete compatible transducer configuration and the manufacturer’s stated conditions.

FAQ

Questions Buyers Ask Most

What is 9200-01-02-02-00 used for?＋

9200-01-02-02-00 is a two-wire Seismoprobe velocity transducer used to measure absolute bearing-housing, casing or structural vibration in compatible machinery-monitoring applications.

What does the 9200-01-02-02-00 code specify?＋

For 9200-01-02-02-00, 01 defines 0° orientation and 4.5 Hz minimum frequency; first 02 is the side-mount connector; second 02 is the circular 1/4-28 UNF base; final 00 means no approvals.

Can 9200-01-02-02-00 be substituted with a similar part number?＋

Do not substitute 9200-01-02-02-00 by appearance or family name alone. Compare the full order code, mounting angle, minimum frequency, mounting base, connector, approvals and compatible monitor or diagnostic-instrument input.

Is 9200-01-02-02-00 a complete measurement system?＋

No. 9200-01-02-02-00 is the sensing transducer, not a complete display or protection system. Use a compatible interconnect cable and monitoring or diagnostic instrument input with the required termination.

What should I provide for a 9200-01-02-02-00 quotation?＋

Send the complete 9200-01-02-02-00 nameplate, quantity, mounting orientation, base and connector requirements, installed monitoring system and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete label and system details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
9200-01-02-02-00

Official manufacturer documentation for Bently Nevada seismoprobe velocity transducer 9200-01-02-02-00.

Official manufacturer datasheet

Bently Nevada datasheet 141626 identifies the 9200 Seismoprobe and defines the 01, 02, 02 and 00 ordering options used in this complete reference.

OPEN OFFICIAL DATASHEET PDF

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements and ordering-code meanings use Bently Nevada / Baker Hughes datasheet 141626 Rev. V.

SEISMOPROBE MEASUREMENT RELATIONSHIP

How 9200-01-02-02-00 Fits into the Vibration Measurement Chain

Bently Nevada is the manufacturer. 9200-01-02-02-00 is a two-wire Seismoprobe velocity transducer. It must be matched to compatible cabling and a suitable monitoring or diagnostic-instrument input.

Bently Nevada · BRAND

Seismoprobe Velocity SystemPRODUCT FAMILY · MEASUREMENT CHAIN

SENSING TRANSDUCER

Transducer

The 9200 moving-coil transducer produces a voltage output proportional to vibration velocity. Confirm the complete mounting and connector options.

INTERCONNECTION

Interconnect Cable

A suitable cable connects the two-wire transducer to the monitoring or diagnostic instrument while maintaining the required termination and environment rating.

MONITORING INPUT

Monitor / Instrument

The Monitor / Instrument conditions the probe signal into a voltage output for monitoring and machinery protection equipment.

System relationship: the transducer orientation, base, connector, cable, load and monitoring input must match the documented Seismoprobe requirements.

APPLICATION AREAS

Application areas for 9200-01-02-02-00

Continuous Vibration MonitoringSupports continuous absolute vibration measurement on compatible machinery.

Periodic Vibration MeasurementSupports periodic measurements with compatible test or diagnostic instruments.

APPLICATION CENTER 9200-01-02-02-00 Seismoprobe Velocity Transducer

Bearing Housing VibrationMeasures vibration velocity at compatible machine bearing housings.

Machine Casing or Structural VibrationSupports casing or structural-vibration measurement at a suitable rigid mounting location.
