/ABB TU508-ETH B8 1SAP214000R0001 Ethernet Communication Interface Terminal Unit

ABB TU508-ETH B8 1SAP214000R0001 Ethernet Communication Interface Terminal Unit

ABB AC500 system · Ethernet communication terminal unit

TU508-ETH B8 1SAP214000R0001

The TU508-ETH B8 1SAP214000R0001 is an ABB terminal unit for Ethernet communication interface modules. It provides 24 V DC spring-terminal connections, two 8-pole RJ45 network connectors and capacity for up to 24 I/O channels, depending on the inserted CI5xx module.

PRODUCT TYPEEthernet terminal unit

PLATFORMABB AC500 system

NETWORK2 × RJ45

I/O CAPACITYMAX. 24 CHANNELS

MANUFACTURERABB

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

ABB ● Ethernet communication terminal unit

ABB AC500 ETHERNET TERMINAL UNIT

TU508-ETH B8 1SAP214000R0001

Ethernet communication terminal unit

Max. 24 channels

MODULE ROLE

TU508-ETH B8 1SAP214000R0001 is an ABB terminal unit for Ethernet communication interface modules. It provides spring-terminal field connections and two RJ45 network ports; match the inserted CI5xx communication interface module and wiring arrangement.

CONFIGURATION NOTE

For TU508-ETH B8 1SAP214000R0001, confirm ordering code 1SAP214000R0001, 24 V DC supply, spring-terminal wiring, CI5xx module compatibility, RJ45 connections and I/O-group allocation before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the TU508-ETH B8 1SAP214000R0001 reference is structured

TU508

Terminal-unit familyEthernet communication interface modules

ETH B8

Communication / markingEthernet · B8 supplied marking

1SAP214000R0001

Exact ABB order code24 V DC · spring terminals

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

ABB AC500 ↗

TU508-ETH B8 1SAP214000R0001 Ethernet communication terminal unit

Engineering data at a glance

Click “+” to expand more specifications.

MODELTU508-ETH B8 1SAP214000R0001

SYSTEMABB AC500

NETWORK PORTS2 × RJ45

I/O CAPACITYMax. 24 channels

ABB Hardware Manual 3ADR010278 identifies TU508-ETH B8 1SAP214000R0001 as a 24 V DC spring-terminal unit for Ethernet communication interface modules.

Official product verification Verify TU508-ETH B8 1SAP214000R0001, the inserted CI5xx module, 24 V DC supply, I/O-group allocation, RJ45 network cabling and terminal wiring before ordering.

GENERAL INFORMATION −

BrandABB

Part numberTU508-ETH B8 1SAP214000R0001

Product typeEthernet communication terminal unit

Product familyABB AC500

Model statusExact ABB order code

PlatformABB AC500

ETHERNET & ORDERING ＋

Communication / markingEthernet

Official order code1SAP214000R0001

Current replacementMatch the installed CI5xx communication interface module

I/O CAPACITY & POWER ＋

Network connectors2 × RJ45, 8-pole

I/O capacityMax. 24 channels in 3 groups of max. 8

Power supply24 V DC

Maximum permitted current10 A via UP, UP3 and ZP

DocumentationABB Hardware Manual 3ADR010278

INSTALLATION & COMPATIBILITY ＋

Reference: Confirm the inserted CI5xx module, grounded DIN rail or wall mounting, 24 V DC supply, network cabling and field-terminal allocation.

Source: ABB Hardware Manual 3ADR010278, section TU507-ETH and TU508-ETH.
