/Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board

Siemens 6ES7288-5DT04-0AA0 SIMATIC S7-200 SMART SB DT04 Digital I/O Signal Board

SIMATIC S7-200 SMART · SB DT04

6ES7288-5DT04-0AA0

The 6ES7288-5DT04-0AA0 is a Siemens SIMATIC S7-200 SMART SB DT04 signal board with 2 digital inputs and 2 transistor outputs at 24 V DC.

DIGITAL INPUTS2 DI

DIGITAL OUTPUTS2 DQ

SUPPLY24 V DC

OUTPUT RATING0.75 A

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● DIGITAL I/O SIGNAL BOARD

SIMATIC S7-200 SMART MODULE

6ES7288-5DT04-0AA0

SB DT04

Digital I/O · 2 DI / 2 DQ

MODULE ROLE

6ES7288-5DT04-0AA0 is a SIMATIC S7-200 SMART SB DT04 digital I/O signal board providing two 24 V DC inputs and two 24 V DC transistor outputs.

CONFIGURATION NOTE

For 6ES7288-5DT04-0AA0, Siemens specifies 2 DI, 2 DQ rated 24 V DC / 0.75 A, a 24 V DC supply range of 20.4 to 28.8 V and typical power loss of 1 W.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this module

6ES7288

Product familySIMATIC S7-200
SMART

5DT04

Module type

0AA0

Order suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗

S7-200 SMART DIGITAL I/O

Engineering data at a glance

Click “+” to expand more specifications.

DIGITAL INPUTS2 × 24 V DC

DIGITAL OUTPUTS2 × 24 V DC

OUTPUT CURRENT0.75 A

POWER LOSS1 W typ.

Official Siemens product data.

Official product verification Verify the complete order number 6ES7288-5DT04-0AA0 and all application, wiring and compatibility requirements before ordering.

General Information −

BrandSiemens

Part number6ES7288-5DT04-0AA0

Product typeSB DT04 Digital I/O Signal Board

Product familySIMATIC S7-200 SMART

Mounting styleSignal-board slot

Engineering softwareSTEP 7 Micro/WIN SMART

Digital Inputs and Outputs ＋

Digital inputs2 inputs at 24 V DC

Digital outputs2 transistor outputs at 24 V DC

Output rating0.75 A per specified output

Electrical and Module Data ＋

Supply voltage24 V DC; permissible 20.4–28.8 V

Channel configuration2 inputs at 24 V DC and 2 transistor outputs at 24 V DC

Input thresholdsState 0: max. 5 V; state 1: min. 15 V

Packaging quantity1 piece

Degree of protectionIP20

Environment and Certification ＋

Packaging dimensions and net weight: 13.00 × 11.3 × 0.75 A; 1 W typ.. Country of origin: China.

Source: Siemens official technical datasheet for 6ES7288-5DT04-0AA0.
