GE IS200PDOAH1B Mark VIe Discrete Output Board

Identify IS200PDOAH1B by the complete GE part number, visible hardware revision, board label, installed output position and the Mark VIe project documentation. Do not treat a similar PDOA code as interchangeable without matching the system bill of material.

Match IS200PDOAH1B to the documented discrete-output arrangement and the supported TRLY or SRLY terminal-board path specified for the project. Verify connectors, output wiring, relay functions and the complete installed architecture before ordering.

IS200PDOAH1B provides the discrete-output interface between the Mark VIe control architecture and the installed relay-output hardware. The exact output assignments and relay functions are determined by the terminal board and project configuration.

Follow the site safety and ESD procedures, then verify the correct I/O position, connector keying, terminal-board match, relay-output wiring and hardware revision. During commissioning, use approved Mark VIe procedures to confirm device recognition and the expected operation of each assigned output.

Evaluate IS200PDOAH1B within the complete Mark VIe discrete-output path. Confirm output assignments, relay-terminal compatibility, commanded state behavior and controller/network mapping from the project records; family similarity alone does not establish migration compatibility.

Use the complete IS200PDOAH1B order number as the baseline. Other PDOA group or revision codes may represent different hardware changes, so confirm the equipment bill of material, board label, installed position, relay-terminal arrangement and GE project documentation before ordering an alternative.
