GE Fanuc IC698CHS009 PACSystems RX7i 9-Slot Rear-Mount Rack

GE FANUC PACSYSTEMS RX7I · 9-SLOT REAR-MOUNT RACK

IC698CHS009

The IC698CHS009 is a GE Fanuc PACSystems RX7i 9-slot rear-mount rack that provides the backplane and module positions for a compatible RX7i system. Verify the exact catalog number, mounting arrangement, module slot widths, enclosure, wiring and airflow before replacement.

PRODUCT TYPE9-SLOT REAR-MOUNT RACK

PLATFORMPACSystems RX7i

MOUNTINGREAR MOUNT

FUNCTIONRX7i MODULE BACKPLANE

MANUFACTURERGE Fanuc

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

GE Fanuc ● 9-SLOT REAR-MOUNT RACK

GE FANUC PACSYSTEMS RX7I

IC698CHS009

9-SLOT REAR-MOUNT RACK

REAR-MOUNT CHASSIS · VME64 BACKPLANE · RX7i MODULE POSITIONS

MODULE ROLE

IC698CHS009 is a GE Fanuc PACSystems RX7i 9-slot rear-mount rack that houses the power supply, CPU and compatible VME64 modules.

CONFIGURATION NOTE

IC698CHS009 is a PACSystems RX7i nine-slot rear-mount rack for installing compatible RX7i CPU, power-supply, communication and I/O modules. Its mounting orientation, backplane connectors, slot assignment, power requirements and cooling clearances must match the installed control system.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

GE Fanuc PACSystems RX7i ↗

IC698CHS009 9-SLOT REAR-MOUNT RACK

Engineering data at a glance

Click “+” to expand more specifications.

RACK TYPE9-slot rear mount

HEIGHT11.15 in (283 mm)

DEPTH7.5 in (190 mm)

WIDTH12.60 in (320 mm)

The rack layout, dimensions and backplane values follow the GE Fanuc PACSystems RX7i installation documentation for IC698CHS009.

Official product configuration Confirm the complete model IC698CHS009, mounting arrangement, slot widths, module placement, enclosure protection, wiring and airflow before ordering.

GENERAL INFORMATION −

BrandGE Fanuc

Part numberIC698CHS009

Product type9-SLOT REAR-MOUNT RACK

Product familyGE Fanuc PACSystems RX7i

Mounting9-slot rear mount

PlatformPACSystems RX7i

RACK & SLOT LAYOUT ＋

Power-supply positionSlot 0; 2.4 in position

Catalog numberIC698CHS009

System checkMatch the exact catalog number, mounting arrangement, slot layout, enclosure and wiring

DIMENSIONS & BACKPLANE ＋

Overall dimensions11.15 in × 12.60 in × 7.5 in

Backplane standardVME64

Module-slot widths0.8 in typical; selected positions wider

Equipment typeOpen equipment

Installation checkVerify enclosure, wiring, module clearances and airflow

INSTALLATION & ENVIRONMENT ＋

Enclosure protection Install in an IP54 or better protective enclosure

Source: GE Fanuc PACSystems RX7i installation documentation identifies IC698CHS009 as a 9-slot rear-mount rack with a VME64 backplane.
