PRODUCT ROLE

TB561-ETH links ABB S500 I/O expansion to a AC500 V3 Ethernet controller and provides 2 × RJ45 interface.

CONFIGURATION NOTE

Confirm order number 1SAP111300R0278, Ethernet project data, device-name switch settings, 24 V DC wiring and the connected S500 module arrangement before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the TB561-ETH order number is structured

TB561

Module familyTerminal base family

ETH / 2ETH

Network variantAC500 V3 Ethernet

1SAP111300R0278

ABB order numberComplete article reference

VERIFIED MANUFACTURER-REFERENCE DATA

Technical Specifications

ABB TB561-ETH ↗

General Information−

BrandABB

ModelTB561-ETH

Order number1SAP111300R0278

Product typeCPU terminal base

Product familyAC500 V3

Supported expansion1 communication-module slot

Ethernet and Ethernet Data+

Ethernet interface100BASE-TX with integrated switch

Connections2 × RJ45 sockets

Transfer rate10/100 Mbit/s, full duplex

Transfer methodEthernet II, IEEE 802.3

Minimum bus cycle1 ms

Conformance classCC B

Supported servicesRTC class 1, RTA, DCP, CL-RPC, LLDP and MRP client

Terminal base and interfaces Data+

Digital inputs8 channels

Digital outputs8 channels

Analog inputs4 channels

Analog outputs2 channels

Input data length19 bytes

Output data length23 bytes

Status indication32 LEDs

Power and Installation+

Process supply24 V DC for inputs and outputs

Maximum terminal load10 A

Communication slotsd fuse10 A, fast

Normal current consumption0.2 A at UP

Maximum power dissipation6 W

MountingHorizontal or vertical with stated derating

CoolingNatural convection; ventilation must not be obstructed

Protection and Diagnostics+

Bus protectionShort circuit, reverse supply, overvoltage and reverse polarity

Galvanic isolationBus interface isolated from the rest of the module

Supported alarmsProcess, diagnostic, return, plug and pull alarms

Device namingTwo rotary switches for explicit device name

Source: ABB TB561-ETH Technical Data and ABB product page for order number 1SAP111300R0278. Values apply under ABB’s stated operating conditions.

FAQ

Questions Buyers Ask Most

What is TB561-ETH used for?+

TB561-ETH is an ABB AC500/S500 CPU terminal base that connects an S500 I/O station to a AC500 V3 Ethernet controller. The module combines 2 × RJ45 interface, integrated I/O and expansion for up to 10 S500 I/O modules.

Does TB561-ETH support the installed processor configuration?+

No. TB561-ETH uses a 100BASE-TX Ethernet physical interface, but its device function is AC500 V3 Ethernet. It supports the ABB-documented Ethernet services and conformance class CC B, so the controller project and device configuration must be compatible.

How many S500 I/O modules can TB561-ETH support?+

TB561-ETH supports a maximum of 10 connected S500 I/O modules. The final station must also satisfy ABB’s power, data-length, mounting and temperature requirements.

Are the the Ethernet interface on TB561-ETH two separate devices?+

No. The two RJ45 sockets on TB561-ETH belong to the integrated Ethernet switch of one AC500 V3 Ethernet device. They support network topology and forwarding rather than two independent device identities.

What must be checked before replacing TB561-ETH?+

Before replacing TB561-ETH, confirm order number 1SAP111300R0278, the standard or XC hardware version, 24 V DC supply wiring, Ethernet device name, GSD/project configuration and the connected S500 I/O module arrangement.

Can TB561-ETH be installed vertically?+

Yes. ABB permits vertical installation of TB561-ETH with specified derating. At +40 °C, the digital output loading is reduced to 50 percent per group, and natural-convection clearance must remain unobstructed.

Which onboard I/O is included with TB561-ETH?+

TB561-ETH includes 8 digital inputs, 8 digital outputs, 4 analog inputs and 2 analog outputs. Channel configuration and connected loads must follow the ABB technical instructions for the required AC500/S500 application.

CONTACT PRODUCT SPECIALIST

Confirm your TB561-ETH configuration with Frida

Share the complete order number, Ethernet project details and connected S500 I/O arrangement for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

✉ sales5@mooreplc.com ◉ +86 153 5940 8275

OFFICIAL DATASHEET

ABB TB561-ETH Product Information

Official ABB product and technical data for TB561-ETH, complete order number 1SAP111300R0278.

TB561-ETH Technical Data

ABB documents TB561-ETH as a CPU terminal base for AC500/S500 with an integrated switch, the Ethernet interface, 10/100 Mbit/s full-duplex communication, terminal-base interfaces and expansion for up to 10 S500 I/O modules.

OFFICIAL DATASHEET ↗

Contact to Get Support

Send the complete model, quantity, Ethernet configuration and your technical or purchasing question.

✉ EMAILsales5@mooreplc.com ◉ WHATSAPP+86 153 5940 8275

Source: ABB official TB561-ETH product page and ABB Automation Builder help for order number 1SAP111300R0278.

AC500 V3 SYSTEM RELATIONSHIP

How TB561-ETH fits into the ABB AC500/S500 system

ABB ↗ is the brand, AC500/S500 is the automation platform, TB561-ETH is the complete module model, CPU terminal base is the product type, and 1SAP111300R0278 is the order configuration used with compatible S500 I/O modules.

BRAND / PLATFORMABB AC500 V3

→

COMPLETE MODELTB561-ETH

→

CONFIGURATION / SYSTEMAC500 V3 Ethernet · 1SAP111300R0278

Controller Connection

AC500 V3 Ethernet controller communication.

Network Topology

Two switched RJ45 Ethernet ports.

Local I/O

Integrated digital and analog channels.

Station Expansion

Up to 10 S500 I/O modules.

SYSTEM APPLICATIONS

Where TB561-ETH fits in the control architecture

AC500 V3 Ethernet Device

Exchanges cyclic and acyclic data with the AC500 V3 Ethernet controller.

S500 I/O Expansion

Supports a connected station of up to 10 S500 I/O modules.

SYSTEM INTERFACETB561-ETHAC500 V3

Switched Ethernet Link

Two RJ45 ports provide an integrated 100BASE-TX switch.

Terminal base and interfaces

Provides local digital and analog I/O within the same station.

ABOUT MOORE AUTOMATION

A trusted industrial automation sourcing partner

Moore Automation Limited supplies industrial automation spare parts to customers worldwide, with dedicated sourcing, part-number verification, pre-shipment confirmation and responsive sales support.
