AC 800M TRIO/GENIUS COMMUNICATION INTERFACE

CI862K01

3BUA000037R1

TRIO/Genius I/O master · one TRIO LAN · up to 30 TRIO blocks · CEX Bus communication interface.

PRODUCT ROLE

CI862K01 connects one ABB TRIO/Genius I/O LAN to an AC 800M controller through the CEX Bus and presents the remote I/O channel data as native controller I/O.

CONFIGURATION NOTE

Confirm article number 3BUA000037R1, the included TP862 baseplate, CEX Bus position, TRIO LAN wiring and termination, controller project data, redundancy arrangement and installed System 800xA version before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the CI862K01 model is structured

CI862

Communication interface

K01

Complete kit variant

VERIFIED ABB MANUFACTURER DATA

Technical Specifications

ABB CI862K01 ↗

General Information−

BrandABB

ModelCI862K01

Article number3BUA000037R1

Product typeTRIO/Genius communication interface kit

Controller familyAC 800M

Lifecycle statusClassic

Kit compositionCI862 interface, TP862 baseplate and mechanics

TRIO/Genius Interface Data+

Network roleMaster interface for one TRIO LAN

ProtocolABB TRIO/Genius I/O

Remote I/O capacityUp to 30 TRIO blocks on one LAN

Controller integrationRemote channel data is handled as native AC 800M I/O

Hand-held monitorDedicated Genius HHM connection

ConnectorsPhoenix 4-pin, DB9 male and DB9 female

Line redundancyNot supported

System Capacity and Configuration+

CI862 units on CEX BusUp to four per AC 800M controller

System I/O scaleUp to 1000 TRIO/Genius I/O points

Module redundancySupported

Hot swapSupported

BaseplateTP862 is included in the CI862K01 kit

Project requirementCI862 hardware and TRIO block configuration must match the controller project

Power and Installation+

24 V current consumption190 mA typical

Dimensions59 × 185 × 127.5 mm

Weight including baseplate700 g

Ingress protectionIP20

Operating temperature+5 to +55 °C

Storage temperature−40 to +70 °C

Relative humidity5 to 95%, non-condensing

Compatibility and Diagnostics+

Controller compatibilityAC 800M with a supported System 800xA version

Required baseplateTP862

TRIO LAN conditionWiring, shielding and termination must match the installed network

Redundant arrangementUse matching CI862 modules and project configuration

Replacement conditionRestore the same CEX Bus position, hardware configuration and TRIO block mapping

Source: ABB CI862 Classic Data Sheet and AC 800M controller hardware documentation for CI862K01 article number 3BUA000037R1.

FAQ

Questions Buyers Ask Most

What is ABB CI862K01 used for?+

CI862K01 is an AC 800M communication-interface kit that connects one TRIO/Genius I/O LAN to the controller through the CEX Bus and manages the remote channel data as native AC 800M I/O.

Which parts are included in CI862K01?+

CI862K01 is the complete kit and includes the CI862 communication interface, the TP862 baseplate and the required mechanics. The complete article number is 3BUA000037R1.

Which protocol and remote I/O does CI862K01 support?+

CI862K01 operates as the master for ABB TRIO/Genius I/O. One interface supports one TRIO LAN with up to 30 TRIO blocks and provides a connection for a Genius Hand Held Monitor.

How many CI862K01 modules can an AC 800M controller use?+

An AC 800M controller can use up to four CI862K01 CEX modules, subject to the supported System 800xA version, controller configuration and the total CEX Bus arrangement. The documented system scale is up to 1000 TRIO/Genius I/O points.

Does CI862K01 support redundancy and hot swap?+

CI862K01 supports module redundancy and hot swap, but the TRIO line itself is not redundant. A redundant replacement requires matching hardware, wiring and controller project configuration.

Can CI862K01 directly replace another communication interface?+

CI862K01 should not be treated as a protocol-neutral replacement. The installed system must use AC 800M, the TP862 baseplate, a correctly configured CEX Bus position and a compatible TRIO/Genius I/O LAN.

What must be checked before installing or replacing CI862K01?+

Before work begins, verify the CI862K01 article number, TP862 baseplate, AC 800M system version, CEX Bus slot, 24 V supply, TRIO LAN wiring and termination, redundancy arrangement, TRIO block mapping and saved controller project.

What information should be supplied when requesting a quote for CI862K01?+

A useful CI862K01 inquiry includes article number 3BUA000037R1, quantity, hardware revision, installed AC 800M controller, System 800xA version, CEX Bus position, redundancy requirement, TRIO block count and clear nameplate photographs.

CONTACT PRODUCT SPECIALIST

Confirm your CI862K01 system configuration with Frida

Share the complete article number, AC 800M system version, CEX Bus position, TP862 baseplate, TRIO LAN wiring, redundancy arrangement and controller project for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

✉ sales5@mooreplc.com ◉ +86 153 5940 8275

OFFICIAL DATASHEET

ABB CI862K01 Product Information

Official ABB manufacturer-reference information for CI862K01, article number 3BUA000037R1, including the current CI862 Classic data sheet.

CI862K01 Technical Data

The ABB CI862K01 is an AC 800M TRIO/Genius communication-interface kit consisting of the CI862 interface, TP862 baseplate and mechanics. One module supports one TRIO LAN with up to 30 TRIO blocks; module redundancy and hot swap are supported, while line redundancy is not. Confirm article number 3BUA000037R1, CEX Bus position, 24 V supply, TRIO wiring, controller project and installed System 800xA version before replacement.

OFFICIAL DATASHEET ↗

Contact to Get Support

Send the complete model, article number, quantity, hardware revision, installed controller or interface and your technical or purchasing question.

✉ EMAILsales5@mooreplc.com ◉ WHATSAPP+86 153 5940 8275

Source: ABB CI862 Classic Data Sheet and ABB AC 800M Controller Hardware documentation.

ABB SYSTEM RELATIONSHIP

How CI862K01 fits into the ABB AC 800M and TRIO/Genius I/O system

ABB ↗ is the manufacturer, AC 800M is the controller platform, CI862K01 is the complete communication-interface kit and TRIO/Genius I/O integration through the CEX Bus is its system role.

BRAND / PLATFORMABB · AC 800M

→

COMPLETE MODELCI862K01

→

PRODUCT ROLETRIO/Genius I/O communication interface

PROTOCOL

ABB TRIO/Genius I/O

CAPACITY

Up to 30 TRIO blocks

BASEPLATE

TP862 included

REDUNDANCY

Module supported

INSTALLATION AND PROCUREMENT

What to confirm for CI862K01

Product Function

connects one TRIO/Genius I/O LAN to an AC 800M controller through the CEX Bus and manages remote channel data as native controller I/O.

Complete Identifier

3BUA000037R1

SYSTEM COMPONENTCI862K01TRIO/GENIUS COMMUNICATION INTERFACE KIT

Configuration Check

Confirm article number 3BUA000037R1, the TP862 baseplate, supported System 800xA version, CEX Bus position, 24 V supply, TRIO LAN wiring and termination, redundancy arrangement and controller project before replacement.
