ABB AC500 / S500 · EtherCAT

CI512-ETHCAT

The ABB CI512-ETHCAT is an AC500/S500 EtherCAT slave interface with two 100BASE-TX ports, 8 digital inputs, 8 digital outputs and 8 software-configurable digital I/O channels. S500 expansion requires device index C0 or above.

NETWORKEtherCAT
ETHERNET2 × RJ45 · 10/100 Mbps
EXPANSIONUp to 10 S500 Modules
SUPPLY24 V DC
MANUFACTURERABB
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Inquire Now
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
ABB ↗ETHERCAT SLAVE DEVICE
AC500 / S500 COMMUNICATION INTERFACE

CI512-ETHCAT

1SAP221000R0001

EtherCAT slave interface · 2-port 100BASE-TX switch · 8 DI · 8 DO · 8 configurable digital I/O.

PRODUCT ROLE

CI512-ETHCAT connects integrated and compatible S500 digital I/O to an EtherCAT master through two switched RJ45 line ports.

CONFIGURATION NOTE

Confirm order number 1SAP221000R0001, device index, EtherCAT master/ESI project, line position, 24 V DC wiring and digital channel mapping before replacement.

👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the CI512-ETHCAT order number is structured

CI512
Module familyCommunication interface
ETHCAT
Network variantEtherCAT
1SAP221000R0001
ABB order numberComplete article reference
VERIFIED MANUFACTURER-REFERENCE DATA

Technical Specifications

ABB CI512-ETHCAT ↗
General Information−
BrandABB
ModelCI512-ETHCAT
Order number1SAP221000R0001
Product typeEtherCAT slave communication interface
Product familyAC500 / S500
Product lifecycleActive
Supported expansionUp to 10 S500 I/O modules (device index C0 or above)
EtherCAT and Ethernet Data+
Protocol roleEtherCAT slave
Ethernet interface100BASE-TX with integrated switch
Connections2 × RJ45 sockets
Transfer rate10/100 Mbit/s, full duplex
Communication processorHilscher NETX 100
Acyclic servicesSDO, maximum 1500 bytes
Emergency diagnosticECAT_SLV_DIAG
Integrated I/O Data+
Digital inputs8 × 24 V DC
Digital outputs8 × 24 V DC, 0.5 A maximum per channel
Configurable digital I/O8 channels, selected as inputs or outputs by software
Analog channelsNone
Process data10 bytes input / 14 bytes output
Cam switch functionalitySupported; extended functions require device index C0 or above
Status indication34 LEDs
Power and Installation+
Process supply24 V DC for inputs and outputs
Maximum terminal load10 A
Rated protection fuse10 A, fast
Maximum power dissipation6 W
MountingHorizontal or vertical with stated derating
CoolingNatural convection; ventilation must not be obstructed
Terminal unitTU507-ETH or TU508-ETH
Normal current consumption0.15 A via UP in normal operation
Compatibility and Diagnostics+
Master requirementCompatible EtherCAT master; ABB CM579-ETHCAT is a documented AC500 example
Supported I/O familiesS500 and S500-eCo remote I/O
Safety I/OS500-S is not listed as compatible for this EtherCAT interface
Rotary switchesReserved for future topology extensions; EtherCAT address is position-based
Required terminal unitTU507-ETH or TU508-ETH
Lifecycle phaseActive

Source: ABB CI512-ETHCAT data sheet 3ADR010008, ABB product page for 1SAP221000R0001, and ABB Automation Builder compatibility information. Values apply under ABB’s stated operating conditions.

FAQ

Questions Buyers Ask Most

What role does CI512-ETHCAT perform in an AC500 system?+
CI512-ETHCAT is an ABB EtherCAT slave communication interface that exposes its integrated digital channels and compatible S500 expansion to an EtherCAT master. Its configuration is 8 fixed DI, 8 fixed DO and 8 software-configurable digital I/O, and S500 expansion is available only on device index C0 or above.
Can CI512-ETHCAT operate as the EtherCAT master?+
No. CI512-ETHCAT is an EtherCAT slave, so it requires a compatible master and matching ESI/project configuration. ABB documents CM579-ETHCAT as an AC500 master example; CI512 cannot replace that master function or be commissioned as an independent controller.
How are the eight DC channels on CI512-ETHCAT configured?+
The eight DC channels on CI512-ETHCAT are assigned by software as digital inputs or digital outputs. They are additional to the module’s 8 fixed DI and 8 fixed DO, and the terminal assignment, output load, I/O mapping and program logic must agree before the configurable channels are energized.
When can CI512-ETHCAT support ten S500 expansion modules?+
CI512-ETHCAT supports up to 10 connected S500 I/O modules only when its device index is C0 or above. An index below C0 has no S500 expansion capability, and the chosen S500 or S500-eCo modules must also be supported by the EtherCAT master project; S500-S safety I/O is not listed for this interface.
What do the rotary switches on CI512-ETHCAT control?+
ABB reserves the two rotary switches on CI512-ETHCAT for future topology extensions. The EtherCAT device address is determined by line position, so the switches do not set a Modbus IP byte or a PROFINET device name and should not be copied from another protocol’s commissioning procedure.
How does CI512-ETHCAT differ from CI511-ETHCAT?+
CI512-ETHCAT provides 8 DI, 8 DO and 8 configurable digital I/O, whereas CI511-ETHCAT provides 8 DI, 8 DO, 4 AI and 2 AO. Both are EtherCAT slaves with two RJ45 ports, but they use different order numbers, process-data sizes, terminal functions and project mappings, so they are not drop-in substitutes without engineering review.
Which checks are mandatory before replacing CI512-ETHCAT?+
Before replacing CI512-ETHCAT, confirm order number 1SAP221000R0001, device index, EtherCAT master/ESI project, line position, TU507-ETH or TU508-ETH terminal unit, 24 V DC UP/UP3 wiring, configurable-channel assignments and connected S500 sequence. Remove all supply and process voltage before inserting or removing the module.
Is CI512-ETHCAT still an active ABB product?+
ABB’s CI512 data sheet lists CI512-ETHCAT, order number 1SAP221000R0001, in the Active lifecycle phase. That status identifies the current product entity, but availability, hardware index and compatibility with an installed EtherCAT station must still be confirmed for each order.
CONTACT PRODUCT SPECIALIST

Confirm your CI512-ETHCAT configuration with Frida

Share the complete order number, device index, EtherCAT master/ESI project and connected S500 digital-I/O arrangement for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Product Information for
CI512-ETHCAT 1SAP221000R0001

ABB official documentation identifies CI512-ETHCAT under order code 1SAP221000R0001 as an EtherCAT communication interface module with 8 DI, 8 DO and 8 configurable digital channels.

Official ABB CI512 documentation

ABB specifies CI512-ETHCAT as an EtherCAT slave with 8 digital inputs, 8 digital outputs and 8 configurable digital input/output channels. The complete ABB order code is 1SAP221000R0001.

OPEN OFFICIAL ABB CI512 DATA SHEET ↗

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical values on this page are limited to ABB official documentation for CI512-ETHCAT and order code 1SAP221000R0001.

ABB CI512 MODEL IDENTIFICATION

What CI512-ETHCAT 1SAP221000R0001 identifies

CI512-ETHCAT is the complete ABB model designation: CI512 identifies the communication interface model and ETHCAT identifies the EtherCAT variant. The exact ABB order code is 1SAP221000R0001.

ABB · BRAND
CI512-ETHCAT · 1SAP221000R0001EXACT IDENTIFIERS
MODEL

CI512

ABB AC500/S500 EtherCAT communication interface model.

PROTOCOL SUFFIX

ETHCAT

Identifies the EtherCAT communication variant.

ORDER CODE

1SAP221000R0001

ABB order code for CI512-ETHCAT with 8 DI, 8 DO and 8 configurable digital channels.

System relationship: CI512 = module model; ETHCAT = EtherCAT variant; 1SAP221000R0001 = exact ABB order code.
APPLICATION AREAS

Application areas for CI512-ETHCAT

EtherCAT Remote I/OOperates as an EtherCAT slave in ABB AC500/S500 remote I/O architectures.
Integrated Digital I/OProvides 8 digital inputs, 8 digital outputs and 8 software-configurable digital channels.
APPLICATION CENTER CI512-ETHCAT 1SAP221000R0001 EtherCAT slave · 8 DI · 8 DO · 8 configurable DI/DO
S500 Station ExpansionSupports up to 10 S500 expansion modules on device index C0 or above.
Replacement VerificationConfirm the complete model, order code, device index, terminal unit, network configuration and channel wiring before replacement.
