ABB CI511-ETHCAT AC500 EtherCAT I/O Module
ABB CI511-ETHCAT AC500 EtherCAT I/O Module
ABB CI511-ETHCAT AC500 EtherCAT I/O Module

ABB CI511-ETHCAT AC500 EtherCAT I/O Module

ABB AC500 / S500 · EtherCAT

CI511-ETHCAT

The ABB CI511-ETHCAT is an AC500/S500 EtherCAT slave communication interface with two 100BASE-TX ports, integrated I/O and S500 expansion capability on device index C0 or above.

NETWORKEtherCAT
ETHERNET2 × RJ45 · 10/100 Mbps
EXPANSIONUp to 10 S500 Modules
SUPPLY24 V DC
MANUFACTURERABB
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Inquire Now
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
ABB ↗EtherCAT SLAVE DEVICE
AC500 / S500 COMMUNICATION INTERFACE

CI511-ETHCAT

1SAP220900R0001

EtherCAT slave communication interface · 2-port 100BASE-TX switch · integrated digital and analog I/O.

PRODUCT ROLE

CI511-ETHCAT connects integrated and compatible S500 I/O to an EtherCAT master and provides two switched RJ45 line ports.

CONFIGURATION NOTE

Confirm order number 1SAP220900R0001, device index, EtherCAT master/ESI project, line position, 24 V DC wiring and the connected S500 module arrangement before replacement.

👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the CI511-ETHCAT order number is structured

CI511
Module familyCommunication interface
ETHCAT
Network variantEtherCAT
1SAP220900R0001
ABB order numberComplete article reference
VERIFIED MANUFACTURER-REFERENCE DATA

Technical Specifications

ABB CI511-ETHCAT ↗
General Information−
BrandABB
ModelCI511-ETHCAT
Order number1SAP220900R0001
Product typeEtherCAT communication interface module
Product familyAC500 / S500
Supported expansionUp to 10 S500 I/O modules (device index C0 or above)
EtherCAT and Ethernet Data+
Ethernet interface100BASE-TX with integrated switch
Connections2 × RJ45 sockets
Transfer rate10/100 Mbit/s, full duplex
Transfer methodEthernet II, IEEE 802.3
Communication processorHilscher NETX 100
Acyclic servicesSDO, maximum 1500 bytes
Emergency diagnosticECAT_SLV_DIAG
Integrated I/O Data+
Digital inputs8 channels
Digital outputs8 channels
Analog inputs4 channels
Analog outputs2 channels
Input data length18 bytes
Output data length18 bytes
Status indication32 LEDs
Power and Installation+
Process supply24 V DC for inputs and outputs
Maximum terminal load10 A
Rated fuse10 A, fast
Normal current consumption0.2 A at UP
Maximum power dissipation6 W
MountingHorizontal or vertical with stated derating
CoolingNatural convection; ventilation must not be obstructed
Protection and Diagnostics+
Bus protectionShort circuit, reverse supply, overvoltage and reverse polarity
Galvanic isolationBus interface isolated from the rest of the module
Diagnostic coverageEtherCAT, module and channel diagnostics
Rotary switchesReserved for future topology extensions

Source: ABB CI511 data sheet 3ADR010007 and ABB product information for order number 1SAP220900R0001. Values apply under ABB’s stated operating conditions.

FAQ

Questions Buyers Ask Most

What is CI511-ETHCAT used for?+
CI511-ETHCAT is an ABB AC500/S500 EtherCAT slave communication interface for remote I/O. It provides two 100BASE-TX RJ45 ports, integrated 8 digital inputs, 8 digital outputs, 4 analog inputs and 2 analog outputs, and—on device index C0 or above—supports up to 10 additional S500 I/O modules; operation requires a compatible EtherCAT master and matching project configuration.
Is CI511-ETHCAT an EtherCAT master?+
No. CI511-ETHCAT is an EtherCAT slave that connects its integrated I/O and compatible S500 expansion to an EtherCAT master, such as ABB CM579-ETHCAT in a supported AC500 architecture. It cannot replace a master module, and the master project, ESI/device definition and station topology must match the installed hardware.
Which I/O channels are built into CI511-ETHCAT?+
CI511-ETHCAT includes 8 × 24 V DC digital inputs, 8 × 24 V DC digital outputs rated up to 0.5 A per channel, 4 configurable analog inputs and 2 configurable analog outputs. Analog ranges include voltage, current and supported resistance-temperature-sensor modes, but the selected channel mode, common reference potential and external wiring must follow ABB’s CI511 instructions.
Can CI511-ETHCAT expand with S500 I/O modules?+
CI511-ETHCAT can expand an EtherCAT remote-I/O station by up to 10 S500 I/O modules only when the CI511 device index is C0 or above. Indices below C0 do not provide this expansion capability, and the chosen S500 or S500-eCo modules must also be supported by the EtherCAT master and Automation Builder configuration; S500-S safety I/O is not listed as compatible for this interface.
Do the rotary switches set the EtherCAT address on CI511-ETHCAT?+
No. On CI511-ETHCAT, the two rotary switches are reserved for future topology extensions; ABB documents the EtherCAT device address as being determined by its position in the EtherCAT line. Do not copy PROFINET-style device-name settings or assume that the switches create an independent EtherCAT address.
What is the difference between CI511-ETHCAT and CI512-ETHCAT?+
CI511-ETHCAT combines EtherCAT slave communication with 8 DI, 8 DO, 4 AI and 2 AO, while CI512-ETHCAT uses a digital-I/O-focused configuration with 8 DI, 8 DO and 8 configurable DI/DO channels. Both belong to the ABB S500 EtherCAT interface family, but they are not drop-in substitutes unless the order number, terminal assignment, I/O mapping, process wiring and master project are all revalidated.
What must be confirmed before replacing CI511-ETHCAT?+
Before replacing CI511-ETHCAT, confirm ABB order number 1SAP220900R0001, the device index, EtherCAT master and ESI/project configuration, line position, TU507-ETH or TU508-ETH terminal unit, 24 V DC UP/UP3 wiring, analog ranges, channel loads and the connected S500 module sequence. Remove all supply and process voltage before inserting or removing the module; ABB does not permit replacement while energized.
What is the lifecycle status of CI511-ETHCAT?+
ABB’s CI511 data sheet lists CI511-ETHCAT, order number 1SAP220900R0001, in the Active lifecycle phase. That status identifies the current product entity and ordering configuration, but availability, hardware index and compatibility with an existing AC500/S500 EtherCAT station still need confirmation for each replacement order.
CONTACT PRODUCT SPECIALIST

Confirm your CI511-ETHCAT configuration with Frida

Share the complete order number, device index, EtherCAT master/ESI project and connected S500 I/O arrangement for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
OFFICIAL DATASHEET

ABB CI511-ETHCAT Product Information

Official ABB product and technical data for CI511-ETHCAT, complete order number 1SAP220900R0001.

CI511-ETHCAT Technical Data

ABB documents CI511-ETHCAT as an EtherCAT slave communication interface for AC500/S500 with an integrated switch, two RJ45 ports, 10/100 Mbit/s full-duplex Ethernet, 8 DI, 8 DO, 4 AI and 2 AO. Expansion for up to 10 S500 I/O modules applies only to device index C0 or above.

OFFICIAL DATASHEET ↗

Contact to Get Support

Send the complete model, quantity, EtherCAT configuration and your technical or purchasing question.

Source: ABB CI511 data sheet 3ADR010007 and ABB Automation Builder help for order number 1SAP220900R0001; lifecycle phase is listed as Active.

AC500 / S500 SYSTEM RELATIONSHIP

How CI511-ETHCAT fits into the ABB AC500/S500 system

ABB ↗ is the brand, AC500/S500 is the automation platform, CI511-ETHCAT is the complete module model, EtherCAT communication interface module is the product type, and 1SAP220900R0001 is the order configuration used with compatible S500 I/O modules.

BRAND / PLATFORMABB AC500 / S500
→
COMPLETE MODELCI511-ETHCAT
→
CONFIGURATION / SYSTEMEtherCAT slave · 1SAP220900R0001
Controller Connection

Communication with a compatible EtherCAT master.

Network Topology

Two switched RJ45 Ethernet ports.

Local I/O

Integrated digital and analog channels.

Station Expansion

Up to 10 S500 I/O modules on device index C0 or above.

SYSTEM APPLICATIONS

Where CI511-ETHCAT fits in the control architecture

EtherCAT Slave

Exchanges process and service data with a compatible EtherCAT master; CI511-ETHCAT is not a master module.

S500 I/O Expansion

Supports a connected station of up to 10 S500 I/O modules.

SYSTEM INTERFACECI511-ETHCATAC500 / S500
Switched Ethernet Link

Two RJ45 ports provide an integrated 100BASE-TX switch.

Integrated I/O

Provides local digital and analog I/O within the same station.
