The ABB CI502-PNIO is an AC500/S500 PROFINET digital I/O bus module with two switched RJ45 ports, 8 digital inputs, 8 digital outputs and 8 configurable digital I/O channels. It connects S500 I/O expansion to a PROFINET IO controller.
PROFINET digital I/O bus module · 2-port 100BASE-TX interface · 8 DI · 8 DO · 8 configurable digital I/O.
CI502-PNIO connects an ABB S500 I/O station to a PROFINET IO controller and combines two switched RJ45 ports with fixed and configurable 24 V DC digital channels.
Confirm order number 1SAP220700R0001, the standard or XC hardware version, TU507-ETH or TU508-ETH terminal unit, PROFINET device settings, 24 V DC field wiring and the connected S500 module arrangement before replacement.
Source: ABB CI502-PNIO product information and ABB Automation Builder help for order number 1SAP220700R0001. Values apply under ABB’s stated operating conditions.
Official ABB product and technical data for CI502-PNIO, complete order number 1SAP220700R0001.
ABB documents CI502-PNIO as a PROFINET digital I/O bus module for AC500/S500 with an integrated switch, two RJ45 ports, 10/100 Mbit/s full-duplex communication, 8 digital inputs, 8 digital outputs, 8 configurable digital I/O channels and expansion for up to 10 S500 I/O modules.
OFFICIAL DATASHEET ↗Send the complete model, quantity, PROFINET configuration and your technical or purchasing question.
Source: ABB official CI502-PNIO product page and ABB Automation Builder help for order number 1SAP220700R0001.
ABB ↗ is the brand, AC500/S500 is the automation platform, CI502-PNIO is the complete module model, PROFINET digital I/O bus module is the product type, and 1SAP220700R0001 is the order configuration used with compatible S500 I/O modules.
PROFINET IO controller communication.
Two switched RJ45 Ethernet ports.
8 digital inputs, 8 digital outputs and 8 configurable digital I/O channels.
Up to 10 S500 I/O modules.
Exchanges cyclic and acyclic data with the PROFINET IO controller.
Supports a connected station of up to 10 S500 I/O modules.
Two RJ45 ports provide an integrated 100BASE-TX switch.
Provides fixed and configurable 24 V DC digital I/O within the same station.
