/ABB ACS580-01-171A-2 General Purpose Wall-Mounted Drive

ABB ACS580-01-171A-2 General Purpose Wall-Mounted Drive

ABB · ACS580 GENERAL PURPOSE WALL-MOUNTED DRIVE

ACS580-01-171A-2

The ACS580-01-171A-2 is an ABB ACS580 low-voltage AC general purpose wall-mounted drive. ABB’s official product record identifies the IEC rating as 45 kW, 171 A and 230 V; retain the complete type code for nameplate matching.

MANUFACTURERABB

DRIVE FAMILYACS580

MODEL FAMILYACS580

REFERENCEACS580-01-171A-2

MANUFACTURERABB

PRODUCT TYPElow-voltage AC general purpose wall-mounted drive

CONDITION / WARRANTYOriginal New · One-Year Warranty

VERIFICATION● Exact ABB product record referenced

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

ABB ● ACS580 GENERAL PURPOSE WALL-MOUNTED DRIVE

ABB ACS580 REFERENCE

ACS580-01-171A-2

OFFICIAL ABB DOCUMENTATION

Exact label · installed ABB system · identifier segment · rating and nameplate record

PRODUCT ROLE

ACS580-01-171A-2 is an ABB ACS580 low-voltage AC general purpose wall-mounted drive. ABB’s official product record identifies the IEC rating as 45 kW, 171 A and 230 V.

INSTALLATION CHECK

Confirm ACS580-01-171A-2, the complete identifier, nameplate, power isolation, ratings, control connections, dimensions and mechanical fit before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the ACS580-01-171A-2 identifier is structured

ACS580-01-171A-2 follows ABB's published type-designation structure. ACS580 identifies the product series; 01 identifies wall-mounted construction; 171A-2 identifies 171 A nominal current and the 230 V voltage class.

ACS580

Drive familyACS580 drive family identifier

Wall-mounted construction01 = wall-mounted drive construction

171A-2

Current and voltage rating171A = 171 A nominal output current; 2 = 230 V voltage class

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

ABB ACS580 general purpose drive family

ACS580-01-171A-2

Identification data at a glance

ABB official documentation identifies ACS580-01-171A-2 and states the ratings and physical data shown here.

HEIGHT880 mm

WIDTH284 mm

DEPTH370 mm

WEIGHT54 kg

Official ABB drive identificationMatch the complete ACS580-01-171A-2 identifier and installed ABB drive configuration before ordering.

GENERAL INFORMATION −

BrandABB

Complete referenceACS580-01-171A-2

Product typelow-voltage AC general purpose wall-mounted drive

Official ABB item3AXD50000417469

Rated-voltage class230 V

FrameR7

IEC rating45 kW; 171 A; 230 V

Heavy-duty rating37 kW; 143 A

DocumentationABB product record and ACS580-01 hardware manual

IDENTIFICATION & COMPATIBILITY ＋

Label evidenceComplete ACS580-01-171A-2 identifier as supplied

System evidenceInstalled ACS580 drive configuration

Replacement limitDo not substitute without complete identifier, rating and system confirmation

INSTALLATION & ORDERING ＋

Before ordering or replacement, provide the complete identifier, nameplate photographs, quantity and installed ACS580 drive configuration.

Source: ABB official product record 3AXD50000417469 and ACS580-01 hardware manual; verify the installed drive nameplate before replacement.
