/Woodward 8440-2080 easYgen-2300-5/P1 Genset Controller

Woodward 8440-2080 easYgen-2300-5/P1 Genset Controller

Woodward easYgen-2300 Series · easYgen-2300-5/P1 genset controller

8440-2080

The 8440-2080 is a Woodward easYgen-2300-5/P1 genset controller with 5 A CT inputs and front-panel operation for generator control and synchronization applications. Verify the exact nameplate, revision and configuration before installation.

DEVICE FAMILYeasYgen-2300-5/P1

APPLICATIONGovernor control

CONFIGURATIONVerify nameplate

ORDER NUMBER8440-2080

MANUFACTURERWoodward

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

WOODWARD ● GENSET CONTROLLER

Woodward easYgen-2300 Series

8440-2080

easYgen-2300-5/P1 genset controller · exact variant verification required

Generator set control · synchronization interface

MODULE ROLE

8440-2080 is associated with the Woodward easYgen-2300-5/P1 genset controller family for engine-governor and hydraulic control applications. Verify the exact nameplate and revision.

CONFIGURATION NOTE

For 8440-2080, confirm the easYgen-2300-5/P1 genset controller variant, stroke, return arrangement, hydraulic configuration, connector wiring, approvals and operating environment against the unit nameplate and official Woodward documentation.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the 8440-2080 reference is identified

easYgen-2300-5/P1

Product family

8440-2080

Exact order number

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Woodward easYgen-2300 Series ↗

easYgen-2300-5/P1 ACTUATOR

Engineering data at a glance

Exact order-number data must be confirmed from the nameplate and the applicable Woodward manual.

DEVICE FAMILYeasYgen-2300-5/P1

APPLICATIONGenset control

CONFIGURATIONFront-panel P1 package

ORDER NUMBER8440-2080

Official Woodward family documentation; exact order-number verification required.

Verification RequiredConfirm 8440-2080, the easYgen-2300-5/P1 variant, stroke, return arrangement, hydraulic connections, electrical interface, approvals and revision against the exact unit before installation or replacement.

General Information −

BrandWoodward

Part number8440-2080

Product typeeasYgen-2300-5/P1 genset controller

Product familyWoodward easYgen-2300 Series

Controller modeleasYgen-2300-5/P1

CT input rating5 A

Auxiliary supply12/24 V DC (8 to 40 V DC)

Maximum auxiliary current0.66/0.33 A DC

Measuring voltage120 V AC / 480 V AC

Measuring current5 A AC

Measuring frequency50/60 Hz (40 to 85 Hz)

Digital input voltage12/24 V DC (8 to 40 V DC)

Discrete inputs8 configurable inputs

Relay outputs6 configurable potential-free outputs

Relay contact load2 A AC at 250 V AC

Communication interface1 CAN bus; 1 RS-485 Modbus RTU

Service portUSB or RS-232 via Woodward DPC cable

Operating temperature−20 to 70 °C (−4 to 158 °F)

Dimensions219 × 171 × 61 mm

Housing protectionFront IP65 with screw fastening; IP54 with clamp; back IP20

ApplicationEngine governor and hydraulic control

Exact configurationVerification Required

Integration and Installation Checks ＋

Product varianteasYgen-2300-5/P1 family; verify exact suffix

Interfaces and configurationConfirm from the exact nameplate and installation documentation

System compatibilityMatch the installed Woodward system

Documentation and Compliance ＋

Family manualseasYgen-2300-5/P1 Manual 82560 and easYgen-2300 Series Manual 26006

Exact approvalsCheck markings on the 8440-2080 unit

Listings and Approvals ＋

Official family documentation provides compliance context, but do not assume an approval for 8440-2080 without checking the unit marking and applicable installation supplement.

Source: Woodward easYgen-2300-5/P1 genset controller manual 82560, easYgen-2300 Series manual 26006 and installation supplement 26798; exact public 8440-2080 datasheet not confirmed.

FAQ

Questions Buyers Ask Most

What is 8440-2080 used for?＋

is a Woodward easYgen-2300-5/P1 genset controller with 5 A CT inputs and front-panel operation for generator control and synchronization applications. Verify the exact unit configuration before use.

What product is 8440-2080?＋

8440-2080 is the Woodward easYgen-2300-5/P1 genset controller. Confirm the exact package and revision from the unit nameplate and applicable documentation.

Which configuration details must be checked for 8440-2080?＋

For 8440-2080, confirm the easYgen-2300-5/P1 package, CT input rating, I/O wiring, communications and application settings against the unit nameplate and official Woodward documentation.

Which system is compatible with 8440-2080?＋

Compatibility depends on the installed Woodward system. Match the complete 8440-2080 nameplate, interfaces and settings to the applicable system manual rather than assuming interchangeability.

What approvals apply to 8440-2080?＋

Use the markings on the exact 8440-2080 unit and the applicable Woodward installation documentation. Family-level information must not be treated as proof of approval for an unmarked variant.

Where can documentation for 8440-2080 be found?＋

Woodward Product Specification 37548_B lists 8440-2080 in the easYgen-2300-5/P1 group and documents the controller interfaces and operating configuration.

What must be checked before replacing 8440-2080?＋

Confirm the complete order number, nameplate, revision, interfaces, control settings, approvals and operating environment before replacing or energizing 8440-2080.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
8440-2080

Woodward Product Specification 37548_B lists 8440-2080 in the easYgen-2300-5/P1 group and documents the controller interfaces and operating configuration.

Woodward easYgen-2300-5/P1 genset controller

Woodward Product Specification 37548_B lists 8440-2080 in the easYgen-2300-5/P1 group and documents the controller interfaces and operating configuration.

OFFICIAL PRODUCT SPECIFICATION

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Woodward manufacturer documentation.

WOODWARD 9907 SERIES ACTUATOR RELATIONSHIP

How 8440-2080 Fits the Woodward easYgen-2300-5/P1 Actuator Family

Woodward is the brand; easYgen-2300-5/P1 is the actuator family; and 8440-2080 is the order number that must be matched to the exact unit configuration.

Woodward · BRAND

Woodward easYgen-2300-5/P1ACTUATOR FAMILY · EXACT CONFIGURATION VERIFICATION

CONTROLLER MODEL

easYgen-2300-5/P1 · 8440-2080

is a Woodward easYgen-2300-5/P1 genset controller with 5 A CT inputs and front-panel operation for generator control and synchronization applications. Verify the exact 8440-2080 application.

MEASUREMENT PACKAGE

FRONT-PANEL P1 PACKAGE

Order number 8440-2080 requires confirmation of the product interfaces and application settings.

COMMUNICATIONS

GENERATOR SET CONTROL · SYNCHRONIZATION INTERFACE

Match the actuator interface and control settings to the installed Woodward system; do not assume interchangeability.

System relationship: verify the complete 8440-2080 nameplate, actuator configuration, hydraulic and electrical connections, approvals and operating environment before installation or replacement.
