/Woodward 8440-2050 easYgen-3200-5/P1 Genset Controller

Woodward 8440-2050 easYgen-3200-5/P1 Genset Controller

Woodward easYgen-3000 · easYgen-3200-5/P1

8440-2050

The 8440-2050 is a Woodward easYgen-3200-5/P1 genset controller with 5 A CT inputs, front-panel mounting and a color graphical display for multiple-unit generator operation.

CT INPUTS5 A

MOUNTINGFront panel

DISPLAYColor LCD

MODEL PACKAGEP1

MANUFACTURERWoodward

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

WOODWARD ● GENSET CONTROLLER

Woodward easYgen-3200

8440-2050

easYgen-3200-5/P1 · 5 A CT

Front-panel controller · Color display

MODULE ROLE

8440-2050 is the Woodward easYgen-3200-5/P1 genset controller for generator measurement, breaker control, synchronization, load sharing and isolated or mains-parallel multiple-unit operation.

CONFIGURATION NOTE

For 8440-2050, Woodward specifies the easYgen-3200 P1 package with 5 A CT inputs, front-panel mounting, a color display, 12 configurable alarm inputs, up to 12 configurable outputs, two CAN interfaces and RS-232/RS-485 communications.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the easYgen-3200-5/P1 reference is identified

easYgen-3200-5/P1

Model

8440-2050

Part number

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Woodward easYgen-3000 ↗

easYgen-3200-5/P1 GENSET CONTROLLER

Engineering data at a glance

Click “+” to expand more specifications.

CT INPUTS5 A

MOUNTINGFront panel

DISPLAYColor LCD

MODEL PACKAGEP1

Official Woodward product data.

Official product verification Verify part number 8440-2050, the easYgen-3200-5/P1 package, 5 A CT secondary, panel cutout, display, controller revision, wiring and project settings against the official Woodward documentation before installation or replacement.

General Information −

BrandWoodward

Part number8440-2050

Product typeeasYgen-3200-5/P1 Genset Controller

Product familyWoodward easYgen-3000

Mounting styleFront panel with color display

Controller modeleasYgen-3200-5/P1

Controller Inputs and I/O ＋

Current-transformer input5 A CT inputs

Discrete alarm inputs12 configurable inputs (10)

Discrete outputsUp to 12 configurable outputs

Communications and Expansion ＋

CAN interfaces2 FlexCAN interfaces

Serial interfaces1 RS-232 and 1 RS-485 Modbus RTU slave interface

External discrete I/O16 inputs / 16 outputs via CANopen

Analog inputs3 configurable FlexIn inputs

Analog outputs2 configurable outputs

Listings and Approvals ＋

Official listings and approvals: UL/cUL, CSA, LR and ABS Marine, BDEW / VDE-AR-N 4105, and CE.

Source: Woodward official product specification 37258P and industrial products catalog 25182 for part number 8440-2050.

FAQ

Questions Buyers Ask Most

What is Woodward 8440-2050 used for?＋

8440-2050 is the easYgen-3200-5/P1 genset controller for generator measurement, breaker control, synchronization, load sharing and multiple-unit operation. Its 5 A CT package must match the installed current-transformer secondary, wiring and configured generator system.

Does 8440-2050 use 5 A or 1 A current-transformer inputs?＋

8440-2050 is the 5 A CT-input version of the front-mounted easYgen-3200 P1 controller. A 1 A CT installation requires the corresponding Woodward variant, so the CT secondary rating must be verified before replacement or commissioning.

Is 8440-2050 a front-panel or cabinet-back controller?＋

8440-2050 is configured for front-panel mounting with a color graphical display. It is not the cabinet-back version without a display; confirm the panel cutout, connector access, enclosure depth and operator-display requirement before installation.

Which communication interfaces are included with 8440-2050?＋

8440-2050 provides two FlexCAN interfaces plus one RS-232 and one RS-485 Modbus RTU slave interface within the easYgen-3200 package. The active protocol, node settings, termination and connected devices must match the saved controller project.

Can 8440-2050 be used for isolated and mains-parallel generator operation?＋

8440-2050 supports easYgen-3200 applications including isolated, island-parallel, mains-parallel and multiple-unit mains-parallel operation. The breaker arrangement, generator count, load-sharing network, protection settings and plant operating sequence must be engineered for the actual installation.

What changed from 8440-1923 to 8440-2050?＋

8440-2050 replaced the earlier 8440-1923 part number when Woodward adopted a color display for the easYgen-3200. Settings files can share common parameters, but newly introduced or removed parameters must be reviewed and updated manually.

What must be checked before replacing a controller with 8440-2050?＋

8440-2050 requires confirmation of the complete part number, P1 package, 5 A CT inputs, panel mounting, connector wiring, hardware revision, firmware, settings file and load-sharing topology. Compatibility should be verified before transferring configuration or energizing the generator system.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
8440-2050

Official Woodward documentation for the easYgen-3200-5/P1 genset controller, part number 8440-2050.

Woodward easYgen-3200-5/P1

Woodward product specification 37258P identifies 8440-2050 as the easYgen-3200-5/P1 controller with 5 A CT inputs, front-panel mounting, a color display, configurable I/O and CAN plus RS-232/RS-485 communications.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Woodward manufacturer documentation.

easYgen-3000 GENSET CONTROL RELATIONSHIP

How 8440-2050 Fits the Woodward easYgen-3000 System

Woodward is the brand; easYgen-3200 is the product family; and 8440-2050 is the 5 A CT, front-panel P1 package of the easYgen-3200 genset controller.

Woodward · BRAND

Woodward easYgen-3200GENSET CONTROL FAMILY · MULTIPLE-UNIT OPERATION

CONTROLLER MODEL

easYgen-3200-5/P1 · 8440-2050

The easYgen-3200-5/P1 measures generator and mains values, controls breakers and supports synchronization and load sharing in compatible generator systems.

MEASUREMENT PACKAGE

5 A CT INPUTS

Part number 8440-2050 uses 5 A current-transformer inputs and front-panel mounting with a color display; verify the installed CT secondary and panel arrangement.

COMMUNICATIONS

2 CAN · RS-232/485

Two FlexCAN interfaces plus RS-232 and RS-485 communication support controller networking and Modbus RTU slave integration when configured for the installed project.

System relationship: verify the P1 package, 5 A CT wiring, breaker arrangement, communication settings, firmware and load-sharing topology before installation or replacement.

APPLICATION AREAS

Application mind map for 8440-2050

Multiple-Unit Genset ControlGenerator measurement, breaker control, synchronization and load sharing for compatible generator sets

Isolated and Parallel OperationSupport isolated, island-parallel, mains-parallel and multiple-unit mains-parallel applications

APPLICATION CENTER 8440-2050 easYgen-3200-5/P1 genset controller

Front-Panel OperationUse the color graphical display for controller operation, status and configuration

System IntegrationMatch 5 A CT inputs, CAN and serial interfaces to the installed generator project
