Woodward 5430-933 Magnetic Pickup Kit

5430-933 is a magnetic pickup kit used to provide rotational-speed sensing to a compatible Woodward turbine or engine control system. The kit combines the 1680-631 pickup with its mating connector.

5430-933 includes the Woodward 1680-631 magnetic pickup and a mating connector. Confirm that both components are present before installation.

5430-933 uses a 0.625-18, commonly written 5/8-18, mounting thread. The machine port and available engagement must match this thread.

The magnetic pickup supplied in 5430-933 has a 4.5 in thread length. Installation depth and the required sensing gap must be checked before fitting.

Woodward lists 5430-933 with 250 Ω DC resistance. The connected speed-input circuit must be suitable for the pickup signal and wiring.

5430-933 should be substituted only after the thread, thread length, pickup resistance, connector, insertion depth, sensing gap and receiving speed input have been matched. Woodward recommends testing an alternative pickup in the actual application.

For a 5430-933 inquiry, provide the complete kit number, installed controller or speed-input model, mounting-thread details, required insertion depth, connector and wiring information, quantity and destination.
