Siemens 6ES7288-2DE16-0AA0 SIMATIC S7-200 SMART EM DE16 Digital Input Module

SIMATIC S7-200 SMART · EM DE16

6ES7288-2DE16-0AA0

The 6ES7288-2DE16-0AA0 is a Siemens SIMATIC S7-200 SMART EM DE16 expansion module with sixteen 24 V DC digital inputs for higher-density field-sensor wiring.

INPUTS16 DI

TYPESink/Source

INPUT VOLTAGE24 V DC

POWER2.3 W

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● EXPANSION MODULE

SIMATIC S7-200 SMART PLC

6ES7288-2DE16-0AA0

EM DE16

Digital Input Expansion Module

MEASUREMENT ROLE

6ES7288-2DE16-0AA0 is a SIMATIC S7-200 SMART EM DE16 expansion module providing sixteen 24 V DC digital inputs for sensors, switches and status contacts.

CONFIGURATION NOTE

For 6ES7288-2DE16-0AA0, Siemens official data specifies 16 sink/source digital inputs, selectable 0.2–12.8 ms filtering, 105 mA SM-bus current and four isolation groups.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this expansion module

6ES7288

Product familySIMATIC S7-200
SMART

2DE16

Module code

0AA0

Order suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗

S7-200 SMART EXPANSION MODULES

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH4.5 cm

WIDTH10 cm

HEIGHT8.1 cm

WEIGHT0.176 kg

Official Siemens product data.

Official product verification Verify the complete order number 6ES7288-2DE16-0AA0and electrical version against the current official Siemens datasheet before ordering.

General Information −

BrandSiemens

Part number6ES7288-2DE16-0AA0

Product typeDigital Input Expansion Module

Product familySIMATIC S7-200 SMART

Mounting styleDIN rail

Configuration softwareSTEP 7 Micro/WIN SMART

Digital Input Specifications ＋

Digital inputs16 DI, 24 V DC

Input typeSink/Source (IEC Type 1 sink)

Selectable filter time0.2 to 12.8 ms

Electrical and Installation ＋

SM bus current105 mA

Isolation groups4

Input current4 mA per active input

Power consumption2.3 W

Maximum input cable500 m shielded / 300 m unshielded

Environment and Certification ＋

Install and wire the module according to the Siemens IM60 System Manual, observing the four isolation groups, 24 V DC input limits and cabinet conditions.

Source: Siemens official SIMATIC ET 200 SMART IM60 System Manual for 6ES7288-2DE16-0AA0.

FAQ

Questions Buyers Ask Most

How many field inputs does 6ES7288-2DE16-0AA0 add?＋

6ES7288-2DE16-0AA0 adds 16 digital inputs at 24 V DC, giving machine builders twice the input density of the 8-channel EM DE08 in the same 45 mm module width.

How are the input channels grouped on 6ES7288-2DE16-0AA0?＋

6ES7288-2DE16-0AA0 divides its 16 inputs into four isolated groups. Plan the common and sensor supply wiring by group before terminating the field cable.

What voltage levels are recognized by 6ES7288-2DE16-0AA0?＋

6ES7288-2DE16-0AA0 uses nominal 24 V DC sink/source inputs; Siemens specifies logic 1 from 15 V at 2.5 mA and logic 0 up to 5 V at 1 mA.

Can the input filtering of 6ES7288-2DE16-0AA0 be adjusted for noisy signals?＋

6ES7288-2DE16-0AA0 supports selectable digital-input filter times from 0.2 ms to 12.8 ms. The filter is configured in groups of four channels to balance response speed and noise rejection.

What cabinet space and power should be allowed for 6ES7288-2DE16-0AA0?＋

6ES7288-2DE16-0AA0 measures 45 × 100 × 81 mm, weighs about 176 g, consumes approximately 2.3 W and draws 105 mA from the SM bus.

What cable lengths are supported by 6ES7288-2DE16-0AA0?＋

6ES7288-2DE16-0AA0 supports digital-input runs up to 500 m with shielded cable or 300 m with unshielded cable, subject to correct routing, grounding and cabinet practice.

What details are needed to quote 6ES7288-2DE16-0AA0 correctly?＋

For 6ES7288-2DE16-0AA0, provide the CPU order number, available SM-bus position, number of 24 V DC sensors, sink/source wiring arrangement, required cable length, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
6ES7288-2DE16-0AA0

Official Siemens documentation for the SIMATIC S7-200 SMART EM DE16.

SIMATIC S7-200 SMART EM DE16

Siemens official IM60 system-manual PDF for 6ES7288-2DE16-0AA0, including digital-input, filtering, isolation, current-consumption, dimension and wiring data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-200 SMART SYSTEM RELATIONSHIP

How EM DE16 Extends a SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-2DE16-0AA0 is the EM DE16 high-density digital-input expansion module connected through the SM bus.

Siemens · BRAND

SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM

EXPANSION ROLE

EM DE16

EM DE16 adds sixteen 24 V DC sensor and switch inputs to the configured controller.

INPUT / OUTPUT CIRCUITS

24 V DC FIELD SIGNALS

Sixteen sink/source inputs accept nominal 24 V DC field signals with selectable filtering in groups of four.

INSTALLATION DATA

45 × 100 × 81 mm

The 45 × 100 × 81 mm module draws 105 mA from the SM bus and is installed beside the supported controller.

System relationship: verify CPU module support, the available expansion position, four isolated input groups and all sixteen 24 V DC field circuits.

APPLICATION AREAS

Application examples for the S7-200 SMART EM DE16

Sensor ExpansionAdds sixteen inputs for proximity, limit and photoelectric sensors

Machine InterlocksCollects a larger set of guards, pressure switches and auxiliary contacts

APPLICATION CENTER EM DE16 Sixteen-channel digital input expansion

Building SignalsMonitors status contacts from multiple pumps, fans and panels

OEM EquipmentAdds high-density 24 V DC input capacity to standard machine designs
