Siemens 6ES7288-1CR60-0AA1 SIMATIC S7-200 SMART CPU CR60s Controller

SIMATIC S7-200 SMART · CPU CR60s

6ES7288-1CR60-0AA1

The 6ES7288-1CR60-0AA1 is a Siemens SIMATIC S7-200 SMART CPU CR60s PLC with 36 digital inputs, 24 relay outputs and integrated RS485 serial communication.

INPUTS36 DI

OUTPUTS24 Relay

SUPPLY85–264 VAC

MEMORY20 KB

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● STANDARD CPU

SIMATIC S7-200 SMART PLC

6ES7288-1CR60-0AA1

CPU CR60s

Standard CPU · AC/DC/Relay

MEASUREMENT ROLE

6ES7288-1CR60-0AA1 is a standard SIMATIC S7-200 SMART CPU with onboard 36 DI at 24 V DC, 24 relay outputs rated 2 A and integrated communication interfaces.

CONFIGURATION NOTE

For 6ES7288-1CR60-0AA1, Siemens specifies an 85–264 V AC, 47–63 Hz supply, 20 KB program/data memory and one onboard RS485 serial interface.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this CPU

6ES7288

Product familySIMATIC S7-200
SMART

1CR60

CPU version

0AA1

Order suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗

S7-200 SMART CPU FAMILY

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH11 cm

WIDTH10 cm

HEIGHT8.1 cm

WEIGHT0.620 kg

Official Siemens product data.

Official product verification Verify the complete order number 6ES7288-1CR60-0AA1and electrical version against the current official Siemens datasheet before ordering.

General Information −

BrandSiemens

Part number6ES7288-1CR60-0AA1

Product typeCPU CR60s AC/DC/Relay

Product familySIMATIC S7-200 SMART

Mounting styleDIN rail

Engineering softwareSTEP 7 Micro/WIN SMART

Onboard I/O and Memory ＋

Digital inputs36 DI, 24 V DC

Digital outputs24 relay outputs, 2 A

Program / data memory20 KB total

Performance and Communication ＋

Bit execution time150 ns

ExpansionFixed onboard I/O; no expansion modules

Serial interfaceRS485

Power loss20 W maximum

Functions6 counters, up to 8 PID loops

Environment and Certification ＋

Operating temperature: −20 to +60 °C for horizontal mounting and −20 to +50 °C for vertical mounting. Maximum relative humidity is 95%, non-condensing.

Source: Siemens official technical datasheet for 6ES7288-1CR60-0AA1.

FAQ

Questions Buyers Ask Most

Which machine applications suit 6ES7288-1CR60-0AA1?＋

6ES7288-1CR60-0AA1 suits larger standalone machines that need many fixed digital signals, relay switching and serial device integration without expansion modules.

What fixed I/O capacity is built into 6ES7288-1CR60-0AA1?＋

6ES7288-1CR60-0AA1 includes 36 digital inputs at 24 V DC and 24 relay outputs, for 60 onboard digital points.

How should the relay loads on 6ES7288-1CR60-0AA1 be divided?＋

The 24 relay outputs on 6ES7288-1CR60-0AA1 should be grouped by voltage and inrush category; use external protection or interposing relays for loads outside the permitted contact rating.

What cabinet space and dissipation apply to 6ES7288-1CR60-0AA1?＋

6ES7288-1CR60-0AA1 is approximately 175 × 100 × 81 mm, weighs about 620 g and has roughly 20 W maximum power loss.

What memory and high-speed counting does 6ES7288-1CR60-0AA1 support?＋

6ES7288-1CR60-0AA1 provides 12 KB program plus 8 KB data memory and four single-phase counters up to 100 kHz, with two A/B-phase counters up to 50 kHz.

Can 6ES7288-1CR60-0AA1 connect directly to PROFINET?＋

6ES7288-1CR60-0AA1 is a serial-only compact CPU with onboard RS485; it does not provide onboard PROFINET, so use a gateway or select a network-capable CPU.

Which project data are needed to quote 6ES7288-1CR60-0AA1?＋

To quote 6ES7288-1CR60-0AA1, send the nameplate, firmware, supply voltage, 36-input/24-output assignment, relay-load details, RS485 topology, backup status, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
6ES7288-1CR60-0AA1

Official Siemens documentation for the SIMATIC S7-200 SMART CPU CR60s.

SIMATIC S7-200 SMART CPU CR60s

Siemens technical datasheet for 6ES7288-1CR60-0AA1, including electrical, I/O, memory, communication, environmental, dimension and weight data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-200 SMART SYSTEM RELATIONSHIP

How CPU CR60s Fits into the SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-1CR60-0AA1 is the CPU CR60s AC/DC/Relay model with onboard I/O and communication.

Siemens · BRAND

SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM

PROCESSING CORE

CPU CR60s

CPU CR60s executes the user program and manages its onboard 36 digital inputs and 24 relay outputs.

ENGINEERING

STEP 7 Micro/WIN SMART

STEP 7 Micro/WIN SMART is used to configure, program and commission the S7-200 SMART CPU.

COMMUNICATION

RS485 serial communication

The integrated RS485 port supports PPI, Modbus RTU, USS and free-port communication.

System relationship: verify the complete CPU order number, power version, I/O needs and the fixed onboard I/O and RS485 communication requirements.
