Siemens 6ES7288-1CR40-0AA1 SIMATIC S7-200 SMART CPU CR40s Controller

SIMATIC S7-200 SMART · CPU CR40s

6ES7288-1CR40-0AA1

The 6ES7288-1CR40-0AA1 is a Siemens SIMATIC S7-200 SMART CPU CR40s PLC with 24 digital inputs, 16 relay outputs and integrated RS485 serial communication.

INPUTS24 DI

OUTPUTS16 Relay

SUPPLY85–264 VAC

MEMORY20 KB

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● STANDARD CPU

SIMATIC S7-200 SMART PLC

6ES7288-1CR40-0AA1

CPU CR40s

Standard CPU · AC/DC/Relay

MEASUREMENT ROLE

6ES7288-1CR40-0AA1 is a standard SIMATIC S7-200 SMART CPU with onboard 24 DI at 24 V DC, 16 relay outputs rated 2 A and integrated communication interfaces.

CONFIGURATION NOTE

For 6ES7288-1CR40-0AA1, Siemens specifies an 85–264 V AC, 47–63 Hz supply, 20 KB program/data memory and one onboard RS485 serial interface.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this CPU

6ES7288

Product familySIMATIC S7-200
SMART

1CR40

CPU version

0AA1

Order suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗

S7-200 SMART CPU FAMILY

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH11 cm

WIDTH10 cm

HEIGHT8.1 cm

WEIGHT0.440 kg

Official Siemens product data.

Official product verification Verify the complete order number 6ES7288-1CR40-0AA1and electrical version against the current official Siemens datasheet before ordering.

General Information −

BrandSiemens

Part number6ES7288-1CR40-0AA1

Product typeCPU CR40s AC/DC/Relay

Product familySIMATIC S7-200 SMART

Mounting styleDIN rail

Engineering softwareSTEP 7 Micro/WIN SMART

Onboard I/O and Memory ＋

Digital inputs24 DI, 24 V DC

Digital outputs16 relay outputs, 2 A

Program / data memory20 KB total

Performance and Communication ＋

Bit execution time150 ns

ExpansionFixed onboard I/O; no expansion modules

Serial interfaceRS485

Power loss18 W maximum

Functions6 counters, up to 8 PID loops

Environment and Certification ＋

Operating temperature: −20 to +60 °C for horizontal mounting and −20 to +50 °C for vertical mounting. Maximum relative humidity is 95%, non-condensing.

Source: Siemens official technical datasheet for 6ES7288-1CR40-0AA1.

FAQ

Questions Buyers Ask Most

What is 6ES7288-1CR40-0AA1 designed to control?＋

6ES7288-1CR40-0AA1 is a compact serial SIMATIC S7-200 SMART AC/DC/relay CPU for standalone machines that need a fixed set of digital signals and RS485 communication.

How many onboard I/O points does 6ES7288-1CR40-0AA1 provide?＋

6ES7288-1CR40-0AA1 provides 24 digital inputs at 24 V DC and 16 relay outputs, giving 40 fixed onboard digital points.

What power and panel allowance are required for 6ES7288-1CR40-0AA1?＋

6ES7288-1CR40-0AA1 accepts 85–264 V AC at 47–63 Hz; allow about 18 W power loss and approximately 125 × 100 × 81 mm of device space.

How much memory and counter capacity does 6ES7288-1CR40-0AA1 have?＋

6ES7288-1CR40-0AA1 provides 12 KB program memory, 8 KB data memory and four single-phase high-speed counters up to 100 kHz.

How does 6ES7288-1CR40-0AA1 communicate with an HMI or drive?＋

6ES7288-1CR40-0AA1 uses its onboard RS485 port for supported serial protocols; projects requiring Ethernet or PROFINET should use an appropriate gateway or a different CPU.

Can expansion modules be added to 6ES7288-1CR40-0AA1 later?＋

6ES7288-1CR40-0AA1 is a compact non-expandable CPU with no signal-module or signal-board expansion, so verify all 40 I/O points before panel release.

What should a buyer provide when replacing 6ES7288-1CR40-0AA1?＋

For 6ES7288-1CR40-0AA1, provide the full nameplate, firmware, 85–264 V AC supply, input count, relay-load voltage/current/inrush, RS485 settings, program backup, quantity and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
6ES7288-1CR40-0AA1

Official Siemens documentation for the SIMATIC S7-200 SMART CPU CR40s.

SIMATIC S7-200 SMART CPU CR40s

Siemens technical datasheet for 6ES7288-1CR40-0AA1, including electrical, I/O, memory, communication, environmental, dimension and weight data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-200 SMART SYSTEM RELATIONSHIP

How CPU CR40s Fits into the SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-1CR40-0AA1 is the CPU CR40s AC/DC/Relay model with onboard I/O and communication.

Siemens · BRAND

SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM

PROCESSING CORE

CPU CR40s

CPU CR40s executes the user program and manages its onboard 24 digital inputs and 16 relay outputs.

ENGINEERING

STEP 7 Micro/WIN SMART

STEP 7 Micro/WIN SMART is used to configure, program and commission the S7-200 SMART CPU.

COMMUNICATION

RS485 serial communication

The integrated RS485 port supports PPI, Modbus RTU, USS and free-port communication.

System relationship: verify the complete CPU order number, power version, I/O needs and the fixed onboard I/O and RS485 communication requirements.
