Siemens 6ES7288-1CR40-0AA0 SIMATIC S7-200 SMART CPU CR40 Controller

SIMATIC S7-200 SMART · CPU CR40

6ES7288-1CR40-0AA0

The 6ES7288-1CR40-0AA0 is a Siemens SIMATIC S7-200 SMART CPU CR40 PLC with 24 digital inputs, 16 relay outputs and integrated RS485 serial communication.

INPUTS24 DI

OUTPUTS16 Relay

SUPPLY85–264 VAC

MEMORY20 KB

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● STANDARD CPU

SIMATIC S7-200 SMART PLC

6ES7288-1CR40-0AA0

CPU CR40

Standard CPU · AC/DC/Relay

MEASUREMENT ROLE

6ES7288-1CR40-0AA0 is a standard SIMATIC S7-200 SMART CPU with onboard 24 DI at 24 V DC, 16 relay outputs rated 2 A and integrated communication interfaces.

CONFIGURATION NOTE

For 6ES7288-1CR40-0AA0, Siemens specifies an 85–264 V AC, 47–63 Hz supply, 20 KB program/data memory and one onboard RS485 serial interface.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this CPU

6ES7288

Product familySIMATIC S7-200
SMART

1CR40

CPU version

0AA1

Order suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗

S7-200 SMART CPU FAMILY

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH11 cm

WIDTH10 cm

HEIGHT8.1 cm

WEIGHT0.440 kg

Official Siemens product data.

Official product verification Verify the complete order number 6ES7288-1CR40-0AA0and electrical version against the current official Siemens datasheet before ordering.

General Information −

BrandSiemens

Part number6ES7288-1CR40-0AA0

Product typeCPU CR40 AC/DC/Relay

Product familySIMATIC S7-200 SMART

Mounting styleDIN rail

Engineering softwareSTEP 7 Micro/WIN SMART

Onboard I/O and Memory ＋

Digital inputs24 DI, 24 V DC

Digital outputs16 relay outputs, 2 A

Program / data memory20 KB total

Performance and Communication ＋

Bit execution time150 ns

ExpansionFixed onboard I/O; no expansion modules

Serial interfaceRS485

Power loss18 W maximum

Functions6 counters, up to 8 PID loops

Environment and Certification ＋

Operating temperature: −20 to +60 °C for horizontal mounting and −20 to +50 °C for vertical mounting. Maximum relative humidity is 95%, non-condensing.

Source: Siemens official technical datasheet for 6ES7288-1CR40-0AA0.

FAQ

Questions Buyers Ask Most

What distinguishes 6ES7288-1CR40-0AA0 from the CR40s version?＋

6ES7288-1CR40-0AA0 is the earlier CPU CR40 ordering variant; verify firmware and project compatibility instead of assuming a CR40s unit is a drop-in replacement.

What onboard I/O does 6ES7288-1CR40-0AA0 provide?＋

6ES7288-1CR40-0AA0 provides 24 digital inputs and 16 relay outputs, for 40 fixed onboard digital points.

What are the enclosure and power requirements for 6ES7288-1CR40-0AA0?＋

6ES7288-1CR40-0AA0 uses an 85–264 V AC line supply and a 24 V DC input circuit; allow approximately 125 × 100 × 81 mm and about 18 W power loss.

How much working memory is available in 6ES7288-1CR40-0AA0?＋

6ES7288-1CR40-0AA0 provides 12 KB program memory and 8 KB data memory, with up to 2 KB of retentive memory for selected data.

What high-speed counting is supported by 6ES7288-1CR40-0AA0?＋

6ES7288-1CR40-0AA0 supports four single-phase high-speed counters up to 100 kHz or two A/B-phase counters up to 50 kHz, subject to the configured input assignment.

Can additional signal modules be fitted to 6ES7288-1CR40-0AA0?＋

6ES7288-1CR40-0AA0 is compact and non-expandable, with no signal-module or signal-board expansion; select another CPU if the final design exceeds 24 DI and 16 relay outputs.

Which checks are essential before ordering 6ES7288-1CR40-0AA0?＋

For 6ES7288-1CR40-0AA0, send the exact nameplate, firmware, supply, I/O allocation, relay inrush data, RS485 settings, program backup, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
6ES7288-1CR40-0AA0

Official Siemens documentation for the SIMATIC S7-200 SMART CPU CR40.

SIMATIC S7-200 SMART CPU CR40

Siemens technical datasheet for 6ES7288-1CR40-0AA0, including electrical, I/O, memory, communication, environmental, dimension and weight data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-200 SMART SYSTEM RELATIONSHIP

How CPU CR40 Fits into the SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-1CR40-0AA0 is the CPU CR40 AC/DC/Relay model with onboard I/O and communication.

Siemens · BRAND

SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM

PROCESSING CORE

CPU CR40

CPU CR40 executes the user program and manages its onboard 24 digital inputs and 16 relay outputs.

ENGINEERING

STEP 7 Micro/WIN SMART

STEP 7 Micro/WIN SMART is used to configure, program and commission the S7-200 SMART CPU.

COMMUNICATION

RS485 serial communication

The integrated RS485 port supports PPI, Modbus RTU, USS and free-port communication.

System relationship: verify the complete CPU order number, power version, I/O needs and the fixed onboard I/O and RS485 communication requirements.
