Siemens 6ES7288-1CR30-0AA0 SIMATIC S7-200 SMART CPU CR30 Controller

SIMATIC S7-200 SMART · CPU CR30

6ES7288-1CR30-0AA0

The 6ES7288-1CR30-0AA0 is a Siemens SIMATIC S7-200 SMART CPU CR30 PLC with 18 digital inputs, 12 relay outputs and integrated RS485 serial communication.

INPUTS18 DI

OUTPUTS12 Relay

SUPPLY85–264 VAC

MEMORY20 KB

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● STANDARD CPU

SIMATIC S7-200 SMART PLC

6ES7288-1CR30-0AA0

CPU CR30

Standard CPU · AC/DC/Relay

MEASUREMENT ROLE

6ES7288-1CR30-0AA0 is a standard SIMATIC S7-200 SMART CPU with onboard 18 DI at 24 V DC, 12 relay outputs rated 2 A and integrated communication interfaces.

CONFIGURATION NOTE

For 6ES7288-1CR30-0AA0, Siemens specifies an 85–264 V AC, 47–63 Hz supply, 20 KB program/data memory and one onboard RS485 serial interface.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this CPU

6ES7288

Product familySIMATIC S7-200
SMART

1CR30

CPU version

0AA1

Order suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-200 SMART ↗

S7-200 SMART CPU FAMILY

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH11 cm

WIDTH10 cm

HEIGHT8.1 cm

WEIGHT0.435 kg

Official Siemens product data.

Official product verification Verify the complete order number 6ES7288-1CR30-0AA0and electrical version against the current official Siemens datasheet before ordering.

General Information −

BrandSiemens

Part number6ES7288-1CR30-0AA0

Product typeCPU CR30 AC/DC/Relay

Product familySIMATIC S7-200 SMART

Mounting styleDIN rail

Engineering softwareSTEP 7 Micro/WIN SMART

Onboard I/O and Memory ＋

Digital inputs18 DI, 24 V DC

Digital outputs12 relay outputs, 2 A

Program / data memory20 KB total

Performance and Communication ＋

Bit execution time150 ns

ExpansionFixed onboard I/O; no expansion modules

Serial interfaceRS485

Power loss14 W maximum

Functions6 counters, up to 8 PID loops

Environment and Certification ＋

Operating temperature: −20 to +60 °C for horizontal mounting and −20 to +50 °C for vertical mounting. Maximum relative humidity is 95%, non-condensing.

Source: Siemens official technical datasheet for 6ES7288-1CR30-0AA0.

FAQ

Questions Buyers Ask Most

What must be checked when identifying 6ES7288-1CR30-0AA0?＋

For 6ES7288-1CR30-0AA0, check the complete nameplate, suffix, firmware and existing wiring before treating it as equivalent to another CR30 generation.

How many field points are associated with 6ES7288-1CR30-0AA0?＋

6ES7288-1CR30-0AA0 is specified here for a 30-point compact layout with 18 digital inputs and 12 relay outputs; confirm this against the installed label.

What relay-load data should be supplied for 6ES7288-1CR30-0AA0?＋

For 6ES7288-1CR30-0AA0, list each load voltage, steady current, inrush current and switching frequency so contactors, valves and motors can be checked correctly.

How should the power circuit for 6ES7288-1CR30-0AA0 be reviewed?＋

Before installing 6ES7288-1CR30-0AA0, verify the 85–264 V AC line supply, protective device, grounding, 24 V DC input circuit and cabinet heat allowance.

Which programming and backup details matter for 6ES7288-1CR30-0AA0?＋

For 6ES7288-1CR30-0AA0, confirm STEP 7 Micro/WIN SMART compatibility, CPU firmware, program password, retained data and availability of a tested project backup.

How are HMI and drive links validated for 6ES7288-1CR30-0AA0?＋

Validation of 6ES7288-1CR30-0AA0 requires the RS485 protocol, baud rate, node addresses, termination and a list of every connected HMI, meter and drive.

What should be sent for a replacement quote for 6ES7288-1CR30-0AA0?＋

Send the full 6ES7288-1CR30-0AA0 nameplate, front and side photos, firmware, I/O list, wiring drawing, load data, serial settings, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

OFFICIAL DATASHEET

Product Information for
6ES7288-1CR30-0AA0

Official manufacturer-reference information for the Siemens SIMATIC S7-200 SMART CPU CR30.

Official datasheet status

No current official Siemens 6ES7288-1CR30-0AA0 datasheet was located in the manufacturer’s public documentation. For product documentation and compatibility details, please contact Product Specialist Frida.

CONTACT FRIDA

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this page are limited to Siemens manufacturer-reference documentation. No third-party product sources were used.

S7-200 SMART SYSTEM RELATIONSHIP

How CPU CR30 Fits into the SIMATIC S7-200 SMART System

Siemens is the brand; SIMATIC S7-200 SMART is the PLC family; and 6ES7288-1CR30-0AA0 is the CPU CR30 AC/DC/Relay model with onboard I/O and communication.

Siemens · BRAND

SIMATIC S7-200 SMARTPLC FAMILY · AUTOMATION SYSTEM

PROCESSING CORE

CPU CR30

CPU CR30 executes the user program and manages its onboard 18 digital inputs and 12 relay outputs.

ENGINEERING

STEP 7 Micro/WIN SMART

STEP 7 Micro/WIN SMART is used to configure, program and commission the S7-200 SMART CPU.

COMMUNICATION

RS485 serial communication

The integrated RS485 port supports PPI, Modbus RTU, USS and free-port communication.

System relationship: verify the complete CPU order number, power version, I/O needs and the fixed onboard I/O and RS485 communication requirements.

APPLICATION AREAS

Application mind map for the S7-200 SMART CPU CR30

Machine ControlLogic and sequence control for compact machines

Packaging LinesOnboard digital I/O and transistor switching

APPLICATION CENTERCPU CR30 Compact PLC automation

Building SystemsControl of pumps, fans and auxiliary equipment

OEM EquipmentCost-effective automation for production equipment
