Siemens 6EP3334-8SB00-0AY0 SITOP PSU8200 24 V DC 10 A Power Supply

Siemens SITOP PSU8200 · 1-Phase 24 V / 10 A

6EP3334-8SB00-0AY0

The 6EP3334-8SB00-0AY0 is a Siemens SITOP PSU8200 stabilized single-phase power supply with automatic 120/230 V AC input-range selection and 24 V DC, 10 A output.

INPUT VOLTAGE120/230 V AC

OUTPUT VOLTAGE24 V DC

OUTPUT CURRENT10 A

INPUT TYPE1-PHASE AC

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● STABILIZED POWER SUPPLY

Siemens SITOP PSU8200

6EP3334-8SB00-0AY0

120/230 V AC · 24 V DC

10 A · ADJUSTABLE 24–28.8 V

MODULE ROLE

6EP3334-8SB00-0AY0 is a Siemens SITOP PSU8200 stabilized single-phase power supply that converts an automatically selected 120/230 V AC input range to regulated 24 V DC at 10 A for compatible industrial control loads.

CONFIGURATION NOTE

For 6EP3334-8SB00-0AY0, Siemens specifies automatic 120/230 V AC range selection, 85–132 V and 170–264 V AC operating ranges, 24 V DC at 10 A, a 24–28.8 V adjustment range, 47–63 Hz input frequency and at least 35 ms mains buffering at rated output.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the 6EP3334-8SB00-0AY0 Order Number Is Structured

6EP3334

SITOP PSU8200 product identifier Siemens SITOP 24 V DC / 10 A power-supply family code

8SB00

PSU8200 configuration segment Identifies the stabilized 120/230 V AC input configuration

0AY0

Complete ordering suffix Retain this suffix when specifying the exact catalog number

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Siemens SITOP PSU8200 ↗

SITOP PSU8200 1-PHASE 24 V / 10 A STABILIZED POWER SUPPLY

Engineering data at a glance

Click “+” to expand more specifications.

INPUT VOLTAGE120/230 V AC

OUTPUT VOLTAGE24 V DC

OUTPUT CURRENT10 A

MOUNTINGDIN RAIL

Official Siemens product data.

Official product verification Verify the complete order number 6EP3334-8SB00-0AY0, automatic 120/230 V AC range selection, 24 V DC / 10 A output, 24–28.8 V adjustment range, mounting clearances and protective-device requirements against the current official Siemens datasheet before ordering.

General Information −

BrandSiemens

Part number6EP3334-8SB00-0AY0

Product typeSITOP PSU8200 1-Phase Stabilized Power Supply, 24 V DC / 10 A

Product familySiemens SITOP PSU8200

Mounting styleDIN rail

Engineering softwareNo engineering software required

Input and Output Ratings ＋

Input voltage120/230 V AC nominal with automatic range selection; 85–132 V and 170–264 V operating ranges

Output voltage24 V DC stabilized

Rated output10 A; 240 W

Module and Ordering Data ＋

Input frequency47–63 Hz

Mains bufferingMinimum 35 ms at rated output

Article statusPM300: Active Product

Packaging quantity1 piece

Lifecycle statusActive product

Environment and Certification ＋

Packaging dimensions and net weight: 14.00 × 14.00 × 8.00 cm; 1.000 kg.

Source: Siemens official SiePortal product data and technical datasheet for 6EP3334-8SB00-0AY0.

FAQ

Questions Buyers Ask Most

What is 6EP3334-8SB00-0AY0 used for?＋

6EP3334-8SB00-0AY0 is a Siemens SITOP PSU8200 stabilized single-phase power supply that converts an automatically selected 120/230 V AC input range into regulated 24 V DC at 10 A for compatible industrial control, instrumentation and automation loads.

What AC input ranges does 6EP3334-8SB00-0AY0 support?＋

6EP3334-8SB00-0AY0 uses automatic range selection for 120/230 V AC systems. Siemens specifies operating ranges of 85–132 V AC and 170–264 V AC; the feeder protection and wiring must follow the official installation data.

What output and overload capability does 6EP3334-8SB00-0AY0 provide?＋

6EP3334-8SB00-0AY0 provides 24 V DC at 10 A with an adjustable 24–28.8 V range. Siemens documents 300% Power Boost for 25 ms and 150% Extra Power for five seconds per minute, subject to the official loading and temperature limits.

Can the output voltage of 6EP3334-8SB00-0AY0 be adjusted?＋

6EP3334-8SB00-0AY0 has a front-adjustable output range of 24–28.8 V DC. The connected load, wiring, protection and any output-voltage derating above 24 V must comply with current Siemens technical data.

What mains buffering does 6EP3334-8SB00-0AY0 provide?＋

6EP3334-8SB00-0AY0 provides at least 35 ms of mains buffering at rated output with a 120/230 V supply. Actual hold-up performance depends on operating conditions defined in the Siemens datasheet.

What installation conditions must be checked for 6EP3334-8SB00-0AY0?＋

6EP3334-8SB00-0AY0 requires a compatible single-phase AC supply, protective earth, IP20 cabinet protection, correct DIN-rail mounting and adequate ventilation. Its -25 to +70 °C operating range includes 2% output-current derating per kelvin above 60 °C.

What information should be included when requesting a quote for 6EP3334-8SB00-0AY0?＋

6EP3334-8SB00-0AY0 should be quoted with the complete order number, quantity, destination, available 120/230 V AC supply, total 24 V DC load, cabinet temperature, mounting space and any required approvals so compatibility and availability can be checked independently.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
6EP3334-8SB00-0AY0

Official Siemens documentation for the Siemens SITOP PSU8200 1-phase 24 V / 10 A stabilized power supply.

Siemens SITOP PSU8200 1-Phase 24 V / 10 A

Siemens technical datasheet for 6EP3334-8SB00-0AY0, including automatic 120/230 V AC range selection, 24 V DC / 10 A output, buffering, overload performance, operating temperature, dimensions and net weight.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

SITOP PSU8200 POWER SUPPLY RELATIONSHIP

How 6EP3334-8SB00-0AY0 Fits the SITOP PSU8200 Power-Supply Family

Siemens is the brand; SITOP PSU8200 is the product family; and 6EP3334-8SB00-0AY0 is the stabilized single-phase 24 V DC / 10 A power supply for compatible industrial control equipment.

Siemens · BRAND

Siemens SITOP PSU8200POWER SUPPLY FAMILY · INDUSTRIAL DC POWER

POWER MODULE

SITOP PSU8200 1-PHASE · 24 V DC / 10 A

6EP3334-8SB00-0AY0 converts an automatically selected 120/230 V AC input range into regulated 24 V DC at 10 A for compatible industrial control and automation loads.

INPUT SUPPLY

120/230 V AC

The nominal input is 120/230 V AC with automatic range selection at 47–63 Hz; Siemens specifies 85–132 V and 170–264 V AC operating ranges.

OUTPUT SUPPLY

24 V DC · 10 A

The stabilized output supplies 24 V DC at 10 A and can be adjusted from 24 to 28.8 V for compatible control-panel loads.

System relationship: verify the automatic AC input range, total DC load, output-voltage setting, cabinet temperature, DIN-rail clearances and upstream protective device.

APPLICATION AREAS

Application mind map for 6EP3334-8SB00-0AY0

SITOP PSU8200 Cabinet PowerSupply regulated 24 V DC power to compatible PLC, I/O and control-panel loads at up to 10 A

Stabilized 24 V DCPower sensors, interface devices and control loads within the 10 A continuous rating

APPLICATION CENTER 6EP3334-8SB00-0AY0 Stabilized 24 V DC power supply

Control Cabinet SupplyConvert the supported 120/230 V AC input ranges into protected 24 V DC control power

DIN-Rail InstallationMount the power supply on a compatible DIN rail with the clearances required by Siemens
