PRODUCT INFORMATION● DATA ACCESS MODULE

1747 DATA TABLE ACCESS MODULE

1747-DTAM-E

PLANT-FLOOR OPERATOR INTERFACE

DH-485 communication · 18–30 V DC input

MODULE ROLE

1747-DTAM-E accesses processor data files, changes operating modes, displays and clears processor faults, and transfers memory between processor RAM and EEPROM.

CONFIGURATION NOTE

Confirm processor compatibility, DH-485 connection, power supply and the required 1747-C10 interconnect cable before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the 1747-DTAM-E order number is structured

1747

Bulletin family1747 product family

DTAM-E

Catalog suffixData Table Access Module catalog suffix

VERIFIED OFFICIAL DATA

Technical Specifications

1747-DTAM-E MANUAL ↗

1747-DTAM-E

Engineering data at a glance

Click “+” to expand the verified information.

Configuration verification

Official manual 1747-UM004 documents 1747-DTAM-E for 18–30 V DC input power and DH-485 communication.

General Information −

BrandPLC

Model1747-DTAM-E

Product categoryData Table Access Module

Verification status1747-UM004 user manual

Electrical and Environmental Data ＋

Input power18–30 V DC

Maximum current2.18–30 V DC

Operating temperature0–55 °C

Communications and Physical Data ＋

Network connectionDH-485 using the 1747-C10 interconnect cable

Physical dimensionsFront 152.4 × 139.7 mm; back case 127 × 101.6 × 63.5 mm

Source: official Data Table Access Module User Manual, publication 1747-UM004.

FAQ

Questions Buyers Ask Most

What is 1747-DTAM-E used for?＋

1747-DTAM-E provides plant-floor access to processor data files, operating modes, processor faults and memory transfer functions.

Which operating modes does 1747-DTAM-E provide?＋

1747-DTAM-E provides 18–30 V DC of standard memory and 2.18–30 V DC of safety memory according to official technical data.

How does 1747-DTAM-E communicate with the processor?＋

1747-DTAM-E can operate point-to-point or as a device on a DH-485 network using the specified interconnect cable.

What power input is documented for 1747-DTAM-E?＋

1747-DTAM-E is documented for 18–30 V DC input power and a maximum current of 104 mA at 24 V DC.

What should I provide for a 1747-DTAM-E quotation?＋

For a 1747-DTAM-E quotation, provide the complete catalog number, processor type, network arrangement, cable requirement, quantity and destination.

CONTACT PRODUCT SPECIALIST

Verify 1747-DTAM-E with Frida

Share the complete label and connected-system details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

OFFICIAL DATASHEET

Manuals and Official References for 1747-DTAM-E

Official publication 1747-UM004 documents the functions, connections, operating modes and specifications of 1747-DTAM-E.

Data Table Access Module User Manual

Official publication 1747-UM004 provides operation, DH-485 communications, power and environmental information for 1747-DTAM-E.
