/PLC 1756-OV32E 32-Point 10-30V DC Electronically Fused Sinking Digital Output Module

PLC 1756-OV32E 32-Point 10-30V DC Electronically Fused Sinking Digital Output Module

1756 SERIES · DIGITAL OUTPUT

1756-OV32E

The 1756-OV32E is a 32-point 10–30 V DC electronically fused sinking digital output module for industrial control applications.

OUTPUT CHANNELS32 POINTS

OUTPUT VOLTAGE10–30 V DC

CURRENT RATING1 A / POINT

ISOLATION250 V

MANUFACTURERPLC

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

PLC ● DISCRETE OUTPUT MODULE

1756 SERIES DIGITAL OUTPUT

1756-OV32E

32 SINKING OUTPUT POINTS

ELECTRONIC FUSING · 36-PIN RTB

MODULE ROLE

1756-OV32E is a 32-channel 10–30 V DC electronically fused sinking output module designed to switch field loads in industrial control systems.

CONFIGURATION NOTE

For 1756-OV32E, the manufacturer specifies 32 output channels, 1 A per point at 10–30 V DC and 250 V continuous isolation between two groups of 16 outputs.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the catalog number identifies this module

1756

Product familyChassis I/O family
DIGITAL OUTPUT MODULE

OV32

32-point sinking output

Electronically fused version

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

1756 Series I/O ↗

1756-OV32E DIGITAL OUTPUT MODULE

Engineering data at a glance

Click “+” to expand more specifications.

LENGTH3.5 cm

WIDTH14.2 cm

HEIGHT14.5 cm

WEIGHT0.2 kg

Manufacturer-reference product data.

Official product verification Verify the complete order number 1756-OV32Eand confirm field voltage, load current, RTB type, wiring method and replacement compatibility against the equipment nameplate before ordering.

General Information −

BrandPLC

Part number1756-OV32E

Product type32-point electronically fused sinking digital output module

Product familyChassis I/O family

Module installationChassis-mounted module; compatible RTB required

Controller platform1756-series industrial controller chassis

Output Configuration ＋

Output channels32 sinking output points

Output groupingTwo groups of 16 outputs

Terminal interface36-pin removable terminal block

Electrical Ratings ＋

Output voltage10–30 V DC

Output current1 A per point

Isolation voltage250 V continuous between groups

Electronic protectionPer-point electronic fusing

Diagnostic timestamp±1 ms

Load and Protection Data ＋

Short-trip specification: 5 A for 20 ms at 24 V DC; verify load inrush and group current limits.

Source: Manufacturer-reference technical data for 1756-OV32E.

FAQ

Questions Buyers Ask Most

What is 1756-OV32E used for?＋

1756-OV32E is used to provide 32 electronically protected DC sinking outputs for solenoids, indicators, interposing relays and other compatible field loads.

How many output points does 1756-OV32E provide?＋

1756-OV32E provides 32 sinking output points arranged as two isolated groups of 16 outputs.

What field voltage does 1756-OV32E require?＋

1756-OV32E operates from 10–30 V DC; the connected loads and field supply must stay within the published per-point and group current limits.

Which protection features are built into 1756-OV32E require?＋

1756-OV32E provides electronic fusing and channel diagnostics, supporting fault isolation and maintenance of the 32-point output circuits.

What isolation does 1756-OV32E require?＋

1756-OV32E provides 250 V continuous isolation between its two output groups of 16 points each.

Is 1756-OV32E suitable for high-inrush loads?＋

1756-OV32E can switch compatible DC loads, but inrush current and group loading must be verified against the exact field device and wiring design before commissioning.

What information is needed to quote 1756-OV32E require?＋

1756-OV32E should be quoted with the complete catalog number, series/revision, RTB requirement, field voltage, load current, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
1756-OV32E

Manufacturer-reference information for the 1756-OV32E digital output module.

Official datasheet status

No datasheet is linked on this page because the available official source contains restricted brand and series wording. Contact Product Specialist Frida for compliant documentation and compatibility checking.

CONTACT FRIDA

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this page are limited to verified manufacturer-reference data; restricted brand and series terms are intentionally omitted.

1756 OUTPUT MODULE RELATIONSHIP

How 1756-OV32E Fits into a Chassis I/O System

PLC identifies the generic product grouping; 1756 series is the chassis I/O family; and 1756-OV32E is the 32-point electronically fused sinking output module.

PLC · PRODUCT GROUP

1756 seriesCHASSIS I/O · DISCRETE OUTPUT

OUTPUT TYPE

32-POINT SINKING OUTPUT

1756-OV32E switches 32 DC field circuits with electronic protection for each output point.

FIELD POWER

10–30 V DC · 1 A/POINT

Use the specified removable terminal block and verify wiring, load polarity and total group current before energizing.

ISOLATION

250 V BETWEEN GROUPS

Two groups of 16 outputs provide published continuous isolation between groups for field-side segmentation.

System relationship: verify catalog number, hardware series, RTB, field voltage, load current, group loading and cabinet wiring.

APPLICATION AREAS

Application mind map for the 1756-OV32E Digital Output Module

Machine Output ControlSwitch solenoids, lamps and interposing relays from 10–30 V DC field circuits

Protected Field WiringUse electronic fusing and channel diagnostics to identify shorted output circuits

APPLICATION CENTER 1756-OV32E 32-point electronically fused sinking digital output module
