Bently Nevada 200151-40-03-00 Accelerometer Interface Cable

200151-40-03-00 is a Bently Nevada accelerometer interface cable that carries the differential sensor signal and excitation between a compatible 20015x accelerometer and supported monitoring electronics. This configuration is 4.0 m long, armored and fitted with standard coupling nuts; both endpoint connectors must match the installed sensor and interface.

The 200151-40-03-00 code specifies a 200151 cable with option 40 for 4.0 m length, option 03 for blue cable with armor, and option 00 for standard coupling nuts. Use it only where the routing length, mechanical protection and mating interfaces match.

No. 200151-40-03-00 is the cable component, not the sensing element. It connects a compatible 200150, 200155 or 200157 accelerometer to supported Trendmaster, ProTIM/flexiTIM or monitor electronics, so the sensor type and channel configuration must still be selected separately.

Not automatically. A 200151 cable has connectors on both ends, while the 200152 family has a connector only at the accelerometer end. Replacement is valid only after confirming both endpoint terminations, total length, coupling-nut style and armor requirement.

The cable is 4.0 m long with a 63.5 mm minimum bend radius and an operating range of −20°C to +100°C. It may be used colder only when it cannot flex or bend; armor, jacket and correctly mated IP67 connectors must remain undamaged.

Confirm the complete part number, 4.0 m route, armored-blue option, standard coupling nuts, both connector mates, sensor family, interface channel, temperature, bend radius and moisture protection. The cable, sensor and monitor must form one compatible measurement chain.
