The ABB DO815 is an S800 I/O digital output module with eight protected 24 V DC high-side channels rated up to 2 A and divided into two isolated groups.
8 high-side outputs · 24 V DC · 2 A maximum per channel · two isolated groups.
DO815 switches eight 24 V d.c. field loads through protected high-side outputs arranged in two isolated groups.
Confirm article number 3BSE013258R1, 24 V DC load supply, output current and inrush, group wiring, compatible MTU, OSP behavior and project fault mode before replacement.
Source: ABB DO815 Data Sheet, article number 3BSE013258R1.
Official ABB manufacturer-reference information for DO815, article number 3BSE013258R1.
The ABB DO815 is an S800 I/O digital output module with eight protected 24 V DC high-side channels rated up to 2 A and divided into two isolated groups. Confirm article number 3BSE013258R1, 24 V DC load supply, output current and inrush, group wiring, compatible MTU, OSP behavior and project fault mode before replacement.
OFFICIAL DATASHEET ↗Send the complete model, article number, quantity, revision, installed system and your technical or purchasing question.
Source: ABB DO815 Data Sheet, article number 3BSE013258R1.
ABB ↗ DO815 is an 8-channel digital output module that switches eight 24 V d.c. field loads through protected high-side outputs arranged in two isolated groups. Its configuration must remain aligned with the installed hardware, wiring and controller project.
Eight protected high-side output channels in two isolated groups.
24 V DC nominal load supply with up to 2 A continuous output per channel under rated conditions.
Short-circuit, overload and output-diagnostic functions are provided.
Confirm the installed MTU, group supply wiring, OSP state and project channel assignment.
Switches eight 24 V DC field loads through protected high-side outputs.
The eight channels are arranged as two isolated groups of four.
Provides field wiring, group supply and mechanical connection for the module.
Transfers output commands, diagnostics and OSP behavior within the S800 I/O station.
