3500/42 Proximitor/Seismic Monitor Module

The 3500/42 Proximitor/Seismic Monitor is a four channel monitor that accepts input from Proximitor and Seismic Transducers and uses this input to drive alarms. The monitor can be programmed using the 3500 Rack Configuration Software to perform any of the following functions: Radial Vibration, Thrust Position, Eccentricity, Differential Expansion, Acceleration, and Velocity.

The primary purpose of the 3500/42 monitor is to provide 1) machinery protection by continuously comparing current machine vibration against configured alarm setpoints to drive alarms and, 2) essential machine vibration information to both operator and maintenance personnel. Alarm setpoints are configured using the 3500 Rack Configuration Software. Alarm setpoints can be configured for each active proportional value and danger setpoints can be configured for two of the active proportional values. When shipped from the factory, the 3500/42 is delivered unconfigured. When needed, the 3500/42 can be installed into a 3500 rack and configured to perform the required monitoring function. This lets you stock a single monitor for use as a spare for many different applications.

The 3500 System provides continuous, online monitoring suitable for machinery protection applications, and is designed to meet the requirements of the American Petroleum Institute’s API 670 standard for such systems. The system’s modular rack-based design includes the following components:
• 3500/05 Instrument Rack (required)
• One or two 3500/15 Power Supplies (required)
• 3500/22M Transient Data Interface (TDI) Module (required)
• One or more 3500/XX Monitor Modules (required)
• One or more 3500/32M (4-channel) or 3500/33 (16-channel) Relay Modules (optional)
• One or two 3500/25 Keyphasor* Modules (optional)
• One or more 3500/92 Communication Gateway Modules (optional)
• Input/Output (I/O) Modules (required)
• 3500/94M VGA Display (optional)
• Internal or external intrinsic safety barriers, or galvanic isolators for hazardous area installations (optional)
• 3500 System Configuration Software (required)
