Siemens 6ES7274-1XF30-0XA0 SIMATIC S7-1200 SIM 1274 Simulator Module 8 Input Switches
Siemens 6ES7274-1XF30-0XA0 SIMATIC S7-1200 SIM 1274 Simulator Module 8 Input Switches
Siemens 6ES7274-1XF30-0XA0 SIMATIC S7-1200 SIM 1274 Simulator Module 8 Input Switches

Siemens 6ES7274-1XF30-0XA0 SIMATIC S7-1200 SIM 1274 Simulator Module 8 Input Switches

SIMATIC S7-1200 · SIM 1274

6ES7274-1XF30-0XA0

The 6ES7274-1XF30-0XA0 is a Siemens SIMATIC S7-1200 simulator module with 8 input switches for CPU 1211 and CPU 1212 controllers.

INPUT SWITCHES8
SIGNAL LEVEL24 V DC
CPU SUPPORT1211 / 1212
MODULE TYPESIM 1274
MANUFACTURERSiemens
CONDITION / WARRANTYOriginal New · One-Year Warranty
ISO CERTIFICATIONISO-Certified Product
VERIFICATION● Product photos and videos provided after inquiry
REQUEST A QUOTE
Inquire Now
MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.
SIEMENS ● INPUT SIMULATOR MODULE
SIMATIC S7-1200 SIM 1274

6ES7274-1XF30-0XA0

SIM 1274 · 8 INPUTS

CPU 1211 / 1212 · 24 V DC

MODULE ROLE
6ES7274-1XF30-0XA0 is a SIMATIC S7-1200 simulator module that provides eight manual 24 V DC input switches for CPU 1211 and CPU 1212 commissioning and program testing.
CONFIGURATION NOTE
For 6ES7274-1XF30-0XA0, Siemens specifies 8 input switches at 24 V DC for CPU 1211/1212; use it for controlled commissioning tests rather than as permanent field I/O.
👩‍💼
WANT THE BEST PRICE?
Frida
Sales Leader 🏆
EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275
ORDER NUMBER BREAKDOWN

How the order number identifies this module

6ES7274
Product familySIMATIC S7-1200
SIMULATOR MODULE
1XF30
SIM 1274 · 8 inputs
0XA0
Order suffix
MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

SIMATIC S7-1200 ↗
SIM 1274 INPUT SIMULATOR MODULE

Engineering data at a glance

Click “+” to expand more specifications.

PACK LENGTH5.0 cm
PACK WIDTH8.4 cm
PACK HEIGHT2.9 cm
NET WEIGHT0.021 kg
Official Siemens product data.
Official product verification Verify the complete order number 6ES7274-1XF30-0XA0and supported CPU type, 8-switch configuration, 24 V DC input behavior and intended commissioning use against the current official Siemens datasheet before ordering.
General Information −
BrandSiemens
Part number6ES7274-1XF30-0XA0
Product typeSIM 1274 Simulator Module, 8 Input Switches
Product familySIMATIC S7-1200
Mounting styleFront connector mounting
Engineering softwareSTEP 7 in TIA Portal
Simulation Interface ＋
Input switches8 manual switches
Signal level24 V DC
Supported CPUsCPU 1211 and CPU 1212
Module and Ordering Data ＋
Primary useCommissioning and program test
Product familySIM 1274 simulator
Article statusActive Product
Packaging quantity1 piece
Lifecycle statusActive Product
Environment and Certification ＋
Packaging dimensions and net weight: 5.0 cm × 8.4 cm × 2.9 cm; 0.021 kg.
Source: Siemens official SiePortal product data and technical datasheet for 6ES7274-1XF30-0XA0.
FAQ

Questions Buyers Ask Most

What is 6ES7274-1XF30-0XA0 used for?＋

6ES7274-1XF30-0XA0 provides eight manual input switches for testing a SIMATIC S7-1200 CPU 1211 or CPU 1212 program during commissioning without wiring eight external field switches.

How many input switches does 6ES7274-1XF30-0XA0 provide?＋

6ES7274-1XF30-0XA0 provides 8 manual input switches for controlled 24 V DC input simulation.

Which S7-1200 CPUs are supported by 6ES7274-1XF30-0XA0 ?＋

6ES7274-1XF30-0XA0 is intended for CPU 1211 and CPU 1212; verify the exact CPU front-connector layout before ordering.

Can 6ES7274-1XF30-0XA0 replace permanent field wiring?＋

6ES7274-1XF30-0XA0 is a commissioning and simulation accessory, not a substitute for validated permanent sensors, switches and field wiring.

What are the packaging dimensions and net weight of 6ES7274-1XF30-0XA0 ?＋

6ES7274-1XF30-0XA0 has official packaging dimensions of 5.0 × 8.4 × 2.9 cm and a net weight of 0.021 kg.

Is 6ES7274-1XF30-0XA0 an active Siemens accessory?＋

6ES7274-1XF30-0XA0 is listed by Siemens as an Active Product, supplied as one piece per package.

What information is needed to quote 6ES7274-1XF30-0XA0 ?＋

6ES7274-1XF30-0XA0 should be quoted with the complete order number, CPU model, intended test setup, required quantity and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD
DATA SHEET

Manuals and Official References for
6ES7274-1XF30-0XA0

Official Siemens documentation for the SIMATIC S7-1200 SIM 1274 simulator module with eight input switches.

SIMATIC S7-1200 SIM 1274

Siemens technical datasheet for 6ES7274-1XF30-0XA0, including supported CPUs, switch count, signal level, lifecycle, packaging dimensions and net weight.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

Technical statements on this product page are based on publicly available official Siemens manufacturer documentation.

S7-1200 SIMULATION ACCESSORY RELATIONSHIP

How SIM 1274 Fits into the SIMATIC S7-1200 System

Siemens is the brand; SIMATIC S7-1200 is the product family; and 6ES7274-1XF30-0XA0 is the eight-input simulator for CPU 1211 and CPU 1212.

Siemens · BRAND
SIMATIC S7-1200PLC FAMILY · COMMISSIONING ACCESSORY
INPUT SIMULATOR MODULE

SIM 1274 · 8 INPUTS

SIM 1274 provides eight manual 24 V DC input switches for controlled CPU 1211/1212 commissioning tests.

ENGINEERING

STEP 7 in TIA Portal

STEP 7 in TIA Portal is used to monitor the CPU program while the SIM 1274 switches exercise the configured digital inputs.

MANUAL INPUT TEST

8 SWITCHES · 24 V DC

The simulator provides repeatable manual states for testing CPU 1211 and CPU 1212 input logic.

System relationship: verify CPU compatibility, front-connector layout, 24 V DC input assignment and safe test procedures.
APPLICATION AREAS

Application mind map for the SIMATIC S7-1200 SIM 1274

Program CommissioningExercise input logic before the final field devices are connected
Training and DemonstrationCreate repeatable switch states for S7-1200 learning systems
APPLICATION CENTER SIM 1274 8-input simulator module
Fault-Sequence TestingSimulate selected input combinations during controlled tests
CPU 1211/1212 Bench TestVerify basic program response on a commissioning bench
