/Siemens 6ES7231-4HA30-0XB0 SIMATIC S7-1200 SB 1231 Analog Input Signal Board 1 AI ±10 V DC 0-20 mA

Siemens 6ES7231-4HA30-0XB0 SIMATIC S7-1200 SB 1231 Analog Input Signal Board 1 AI ±10 V DC 0-20 mA

SIMATIC S7-1200 · SB 1231

6ES7231-4HA30-0XB0

The 6ES7231-4HA30-0XB0 is a Siemens SIMATIC S7-1200 SB 1231 analog input signal board with 1 AI for ±10 V DC or 0-20 mA signals.

ANALOG INPUTS1 AI

VOLTAGE RANGE±10 V DC

CURRENT RANGE0-20 mA

RESOLUTION12 bit

MANUFACTURERSiemens

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

SIEMENS ● ANALOG INPUT SIGNAL BOARD

SIMATIC S7-1200 SB 1231

6ES7231-4HA30-0XB0

1 AI · ±10 V DC

0-20 mA · 12-BIT

MODULE ROLE

6ES7231-4HA30-0XB0 is a SIMATIC S7-1200 SB 1231 signal board that adds one analog input for ±10 V DC or 0-20 mA measurement with 12-bit resolution.

CONFIGURATION NOTE

For 6ES7231-4HA30-0XB0Siemens specifies 1 AI for ±10 V DC or 0-20 mA with 12-bit resolution; select the correct measurement mode and wiring before commissioning.

👩‍💼
