The 1783-USP1S4T is a Stratix 2100 unmanaged Ethernet switch with four 100 Mb copper RJ45 ports and one 100 Mb SFP slot for Layer 2 industrial networking.
Brand :
PLCPart Number :
1783-USP1S4TWeight :
524 gDimension :
114 mm x 26 mm x 70 mm (H x W x D)Country of Origin :
Multiple; verify exact product labelHS Code :
Stratix 2100 Unmanaged Ethernet SwitchDescription :
The 1783-USP1S4T is a Stratix 2100 unmanaged Ethernet switch with four 100 Mb copper RJ45 ports and one 100 Mb SFP slot for Layer 2 industrial networking.Click “+” to expand more specifications.
Source: Official Rockwell Automation technical data 1783-TD002 and the exact product page support the 1783-USP1S4T specifications shown here.
1783-USP1S4T provides unmanaged Layer 2 industrial Ethernet connectivity through four Fast Ethernet copper ports and one Fast Ethernet SFP slot.
1783-USP1S4T provides 5 total ports, including 4 x 100 Mb and 1 x 100 Mb.
1783-USP1S4T serves as stratix 2100 unmanaged ethernet switch in the documented Stratix 2100 product family.
1783-USP1S4T uses 12/24/48 V DC or 24 V AC; verify the installed supply and wiring before connection.
1783-USP1S4T is documented for -40 to +75 °C operation; match the enclosure and site conditions.
1783-USP1S4T is covered by Rockwell Automation publication 1783-IN023 and its exact official product page.
For 1783-USP1S4T, provide the complete catalog number, quantity, nameplate, port media, power and installed-network requirements.
Official manufacturer-reference information for the 1783-USP1S4T stratix 2100 unmanaged ethernet switch.
Rockwell Automation publication 1783-IN023 explicitly covers 1783-USP1S4T and documents its installation and product specifications.
OFFICIAL INSTALLATION INSTRUCTIONSSend the complete model, quantity, nameplate photos and your technical or purchasing question.
Technical statements on this product page are limited to Rockwell Automation publication 1783-IN023 and the exact official product page for 1783-USP1S4T.
1783 identifies bulletin 1783 industrial Ethernet products; USP identifies stratix 2100 unmanaged switch family; 1S identifies one 100 Mb SFP slot; 4T identifies four 100 Mb copper RJ45 ports.
Bulletin 1783 industrial Ethernet products.
Stratix 2100 unmanaged switch family.
One 100 Mb SFP slot.
Four 100 Mb copper RJ45 ports.
Unmanaged Layer 2 connectivity links controllers, HMIs and industrial Ethernet devices in machines.
Four copper ports and one SFP slot support mixed-media local industrial Ethernet connections.
The compact DIN-rail switch supports industrial Ethernet device connections inside control panels.
Fast Ethernet interfaces support straightforward local networks without managed configuration.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
