Introduction of Bently Nevada 3500 Machinery Protection Systems

The 3500 system is the world-leader at detecting and preventing both missed-trips and false-trips in rotating machinery. With over 85,000 installed worldwide, it provides automatic protection value by tripping monitored machines to prevent expensive damage when needed.
The 3500 system also protects your machines and processes against false-trips that could bring your operation down for no reason, resulting in a costly outage or loss of production.
When connected with our System 1† software, it also provides continuous condition monitoring information for use in a proactive maintenance program.

The 3500 system incorporates the industry’s most extensive selection of machinery measurement parameters combined with software configuration for virtually all machinery monitoring scenarios.

The 3500 System provides continuous, online monitoring suitable for machinery protection applications, and is designed to meet the requirements of the American Petroleum Institute’s API 670 standard for such systems. The system’s modular rack-based design includes the following components:
• 3500/05 Instrument Rack (required)
• One or two 3500/15 Power Supplies (required)
• 3500/22M Transient Data Interface (TDI) Module (required)
• One or more 3500/XX Monitor Modules (required)
• One or more 3500/32M (4-channel) or 3500/33 (16-channel) Relay Modules (optional)
• One or two 3500/25 Keyphasor* Modules (optional)
• One or more 3500/92 Communication Gateway Modules (optional)
• Input/Output (I/O) Modules (required)
• 3500/94M VGA Display (optional)
• Internal or external intrinsic safety barriers, or galvanic isolators for hazardous area installations (optional)
• 3500 System Configuration Software (required)
