AB 2711-T10C8L1 PanelView 1000 Color Terminal Touch Screen

Technical Specifications for 2711-T10C8L1

About  2711-T10C8L1

The Allen-Bradley 2711-T10C8L1 is a PanelView Standard operator terminal. This operator terminal is commonly called as a Human Machine Interface (HMI) with the primary purpose of linking data and logic within a Programmable Logic Controller (PLC), display the data via a custom designed interface and permit control via the provided input interface.

The 2711-T10C8L1 provides process visualization via the provided Active Matrix Thin-Film Resistor (TFT) with Cold Cathode Fluorescent (CCF) Backlight. This HMI screen has an effective display area of 211 x 158 mm (8.3 x 6.2 in.), resolution of 640 x 480 pixels. Embedded within the HMI screen are individual touch cells with size of 26 x 30 pixels and distributed in 24 columns x 16 rows.

The 2711-T10C8L1 communicate with partner controllers and devices via the built-in Data Highway Plus (DH+) protocol. This communication protocol is a legacy protocol that is based in RS485 topology. It allows multi-node communication over long distances. Additionally. This operator terminal has One (1) RS232 communication port that is mainly used for communicating with alarm and event printer for documentation and historization.
