AB 1769-IR6 CompactLogix 6 Pt RTD Module

Technical Specifications for 1769-IR6

About  1769-IR6

The Allen-Bradley 1769-IR6 is an analog input module which belong to the Compact I/O product family. This module is specifically used for Resistance Temperature Detectors (RTD) and Resistance signals. This module may be used with MicroLogix 1500 and 1769 CompactLogix controllers. This module also supports installation on distributed IO rack, provided that the communication adapters used are 1769-ADN DeviceNet and 1769-AENTR Ethernet adapter.

Up to support Six (6) RTD instruments may be wired to this module. Compatible RTD types, whether 2,3 or 4-Wire RTDs are Copper 426, Nickel 618, Nickel 672, Nickel-Iron 518, Platinum 385, Platinum 3916. to 2, 3 and 4 wire RTDs. When using 4-wire RTD, one of the compensation wires is not terminated to the terminal. Aside from RTD sensors, this module supports direct wiring of resistance signals such as 150??, 500 ?, 1000 ? and 3000 ?.

Primarily, this module is designed for Temperature applications as RTD sensors are Temperature measuring devices. With resistance signal capability, this module may also be used in determining or measuring displacement or movement of a specific device. Common displacement measurement applications are found in factory automation requirements such as clamping, rotation and other similar tasks.
