ICS Triplex T8311 Trusted TMR Expander Interface

ICS TRIPLEX TRUSTED SYSTEM · TMR EXPANDER INTERFACE

T8311

The T8311 is a Trusted TMR Expander Interface that provides the master connection between the Controller Chassis IMB and the triplicated Expander Bus.

PRODUCT TYPETRUSTED TMR EXPANDER INTERFACE

PLATFORMTrusted Expander System

CONFIGURATION20 Vdc to 32 Vdc

APPLICATIONTMR Expander Interface

MANUFACTURERICS Triplex / Rockwell Automation

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

ICS Triplex ● TRUSTED TMR EXPANDER INTERFACE

ICS TRIPLEX TRUSTED SYSTEM

T8311

TRUSTED TMR EXPANDER INTERFACE

TRUSTED SYSTEM · triplicated Expander Bus · active/standby

MODULE ROLE

T8311 is the fault-tolerant master interface between the Controller Chassis Inter-Module Bus and the Expander Bus, supporting active/standby operation.

CONFIGURATION NOTE

For T8311, confirm the T8100 Controller Chassis slot pair, T8312 adapter, TC-301 or T8314 link and configured active/standby arrangement before replacement.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Rockwell Automation PD-T8311 ↗

T8311 TRUSTED TMR EXPANDER INTERFACE

Engineering data at a glance

Click “+” to expand more specifications.

MODELT8311

PLATFORMTrusted Expander System

CONFIGURATION20 Vdc to 32 Vdc

APPLICATIONController-to-Expander Link

Rockwell Automation Publication PD-T8311 identifies T8311 as the Trusted TMR Expander Interface between the Controller Chassis IMB and Expander Bus.

Official product verification Verify the complete model T8311, T8100 slot pair, T8312 adapter, expander cabling and active/standby configuration before ordering.

GENERAL INFORMATION −

BrandICS Triplex / Rockwell Automation

Part numberT8311

Product typeTrusted TMR Expander Interface

Product familyTrusted Expander System

System roleMaster interface between Controller Chassis IMB and Expander Bus

PlatformTrusted Expander System

MODULE CONFIGURATION ＋

ArchitectureHIFT TMR, fault tolerant

Module locationT8100 Controller Chassis I/O slot

Compatibility checkAdjacent slot pair with T8312 adapter

POWER & COMMUNICATIONS ＋

Backplane supply20 Vdc to 32 Vdc

Power dissipation54 W backplane supply

Expander BusTriplicated, 1.5 Gbps over UTP

Expander distance30 m copper / 10 km with T8314

Dimensions / weight266 x 31 x 303 mm / 1.14 kg

DOCUMENTATION & ORDER CHECK ＋

Reference: Verify the complete model T8311, T8100 slot pair, T8312 adapter, expander cabling and active/standby configuration before ordering.

Source: Rockwell Automation Publication PD-T8311, Issue 15 identifies T8311 as the Trusted TMR Expander Interface variant.

FAQ

Questions Buyers Ask Most

What is T8311 used for?＋

T8311 is the fault-tolerant master interface between the Controller Chassis Inter-Module Bus and the triplicated Expander Bus.

What system connection does T8311 provide?＋

T8311 connects the Controller Chassis IMB to the triplicated Expander Bus and operates with the T8312 Expander Interface Adapter.

Does T8311 support active and standby operation?＋

T8311 supports active and standby modes; paired modules are interlocked so both cannot be active simultaneously.

Which chassis location is specified for T8311?＋

T8311 is installed in a T8100 Controller Chassis I/O slot and configured as part of an adjacent companion-slot pair.

What should be checked before replacing T8311?＋

For T8311, confirm the T8100 slot pair, T8312 adapter, expander cable type, active/standby arrangement and installed-system configuration.

What official manual covers T8311?＋

T8311 is covered by Rockwell Automation Publication PD-T8311, Issue 15, Trusted Expander System.

What information should be supplied when ordering T8311?＋

When ordering T8311, provide the exact catalog number, quantity, T8100 slot pair, T8312 adapter, cabling and active/standby configuration.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Product Information for
T8311

Official Rockwell Automation documentation for Trusted T8311.

Trusted Expander System

Rockwell Automation Publication PD-T8311, Issue 15 describes T8311 as the HIFT TMR master interface between the Controller Chassis IMB and the triplicated Expander Bus.

OFFICIAL MANUAL ↗

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this page follow Rockwell Automation Publication PD-T8311, Issue 15 for the Trusted TMR Expander Interface.

TRUSTED TMR EXPANDER INTERFACE RELATIONSHIP

How T8311 Fits into the Trusted Expander System

Rockwell Automation publishes the Trusted product documentation; T8311 is the HIFT TMR master interface; and T8311 provides the master interface between the Controller Chassis IMB and Expander Bus.

ICS Triplex · BRAND

Trusted Expander Systemtrusted TMR expander interface

SYSTEM ROLE

trusted TMR expander interface

Carries the triplicated Expander Bus over UTP and supports local copper or remote fibre-connected expansion chassis.

NETWORK / POWER

1.5 Gbps Expander Bus · up to 12.5 Mbps IMB

Confirm adjacent slot-pair configuration, T8312 adapter and local or remote expander cabling.

ORDER DATA

T8311 · Trusted TMR Expander Interface

Do not substitute another interface without checking the T8100 slot pair, T8312 adapter, active/standby configuration and expander cabling.

System relationship: verify the exact interface catalog number, T8100 slot pair, T8312 adapter, cabling and active/standby configuration.

APPLICATION AREAS

Application map for T8311

Controller-to-Expander Link54 W backplane supply

Active/Standby RedundancyConfigure adjacent companion slots for supported repair strategies

APPLICATION CENTER T8311 T8311 · Trusted TMR Expander Interface

Local or Remote ExpansionUse TC-301 copper or T8314 fibre link hardware

Replacement VerificationCheck the exact T8311 model, T8100 slots, T8312 adapter and cabling before replacement.
