Honeywell CC-PSP401 51454122-175 Experion Series C Speed Protection Module 4-Channel

EXPERION SERIES C · SPEED PROTECTION

CC-PSP401 51454122-175

The CC-PSP401 51454122-175 is a Honeywell Experion Series C Speed Protection Module for turbomachinery overspeed monitoring, two-out-of-three voting and fast trip protection.

SPEED INPUTS4 CHANNELS

ANALOG I/O8 AI · 1 AO

DIGITAL I/O8 DI · 4 DO

LOOP LATENCYWITHIN 40 ms

MANUFACTURERHoneywell

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

HONEYWELL ● TURBOMACHINERY PROTECTION

EXPERION SERIES C SPEED PROTECTION

CC-PSP401 51454122-175

4 SPEED INPUT CHANNELS

2-OUT-OF-3 VOTING · OVERSPEED TRIP

MODULE ROLE

CC-PSP401 51454122-175 is a Honeywell Experion Series C Speed Protection Module that accepts four speed-probe inputs, performs two-out-of-three voting and initiates overspeed trip protection for turbomachinery.

CONFIGURATION NOTE

For CC-PSP401 51454122-175, Honeywell specifies four active/passive speed inputs, eight analog inputs, one analog output, eight digital inputs, four digital outputs and overall trip-loop latency within 40 ms.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

ORDER NUMBER BREAKDOWN

How the order number identifies this module

Product familyHoneywell Experion Series C

PSP401

Module codeFour-channel speed protection module

51454122

Base part numberManufacturer base identifier

175

Order suffixProduct-specific suffix

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Honeywell Experion Series C ↗

CC-PSP401 SPEED PROTECTION MODULE

Engineering data at a glance

Click “+” to expand more specifications.

SPEED INPUTS4 CHANNELS

ANALOG I/O8 AI · 1 AO

DIGITAL I/O8 DI · 4 DO

LOOP LATENCYWITHIN 40 ms

Official Honeywell product data.

Official product verification Verify the complete order number CC-PSP401 51454122-175and the speed-probe type, input frequency range, I/O requirements, redundancy arrangement, IOTA and C300 controller compatibility against the official Honeywell specification before ordering.

General Information −

BrandHoneywell

Part numberCC-PSP401 51454122-175

Product typeSpeed Protection Module (SPM), 4 channels

Product familyHoneywell Experion Series C

Module installationIOM plugs onto compatible IOTA

Controller platformHoneywell C300 controller

Speed Protection Inputs ＋

Speed input channels4 active/passive probe channels

Voting logicTwo-out-of-three voting

Probe frequency rangesMagnetic pickup 150 Hz–25 kHz; active pickup 1 Hz–10 kHz

Module I/O and Response ＋

Analog I/O8 AI; 1 AO

Digital I/O8 DI; 4 isolated relay outputs

Protection-loop latencyWithin 40 ms

RedundancySupported

Digital input power22–28 V DC

Electrical and Signal Data ＋

Output and accuracy: DI 22–28 V DC; DO up to 230 V AC / 24 V DC; speed-input accuracy 0.05%.

Source: Honeywell official Experion Series C Turbomachinery I/O Specification EP03-540-511 for CC-PSP401 51454122-175.

FAQ

Questions Buyers Ask Most

What is CC-PSP401 51454122-175 used for?＋

CC-PSP401 51454122-175 is used for turbomachinery overspeed monitoring and protection using four speed-probe channels and fast trip logic.

How many speed-probe inputs does CC-PSP401 51454122-175 provide?＋

CC-PSP401 51454122-175 provides 4 active/passive speed inputs for turbine speed measurement and protection.

What voting logic does CC-PSP401 51454122-175 ?＋

CC-PSP401 51454122-175 supports two-out-of-three voting; the onboard logic votes the speed signals and initiates an overspeed trip when the configured condition is met.

Which I/O interfaces are available on CC-PSP401 51454122-175 ?＋

CC-PSP401 51454122-175 provides 8 AI, 1 AO, 8 DI and 4 DO, in addition to four dedicated speed inputs for the protection application.

What protection-loop latency does CC-PSP401 51454122-175 ?＋

CC-PSP401 51454122-175 has an overall protection-loop latency of within 40 ms with speed-point processing of 2.5 ms.

Is CC-PSP401 51454122-175 suitable for redundant protection?＋

CC-PSP401 51454122-175 supports a redundant speed-protection solution, with redundant SPM arrangements described in the Honeywell specification.

What information is needed to quote CC-PSP401 51454122-175 ?＋

CC-PSP401 51454122-175 should be quoted with the full model and part number, speed-probe type, frequency range, IOTA, redundancy requirements, quantity and delivery destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete order number and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
CC-PSP401 51454122-175

Official Honeywell documentation for the Experion Series C CC-PSP401 Speed Protection Module.

Experion Series C CC-PSP401 Speed Protection Module

Honeywell technical specification EP03-540-511 for CC-PSP401 51454122-175, covering speed inputs, voting logic, I/O, latency, redundancy and electrical data.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are based on publicly available official Honeywell manufacturer documentation.

EXPERION SERIES C SPM RELATIONSHIP

How CC-PSP401 Fits into Experion Series C Turbomachinery I/O

Honeywell is the brand; Experion Series C is the product family; and CC-PSP401 51454122-175 is the four-channel Speed Protection Module for turbomachinery overspeed protection.

Honeywell · BRAND

Experion Series CTURBOMACHINERY I/O · PROTECTION SYSTEM

VOTING LOGIC

TWO-OUT-OF-THREE VOTING

CC-PSP401 conditions four speed signals and applies two-out-of-three voting for fast overspeed trip protection.

I/O MIX

4 SPEED · 8 AI · 1 AO · 8 DI · 4 DO

STEP 7 is used to configure the CC-PSP401, program its integrated I/O and counters, and diagnose the Experion Series C station.

C300 INTEGRATION

WITHIN 40 ms LOOP LATENCY

The voted speed can be used by the Honeywell C300 control loop while the SPM maintains a fast overall protection-loop response.

System relationship: verify speed-probe type, input frequency, IOTA, field power, I/O requirements and redundancy arrangement.

APPLICATION AREAS

Application mind map for the Experion Series C CC-PSP401 Speed Protection Module

Turbomachinery ProtectionMonitor rotating equipment speed and provide overspeed trip protection

Fast Protection LogicUse onboard signal conditioning and two-out-of-three voting for rapid trip decisions

APPLICATION CENTER CC-PSP401 Speed Protection Module with four speed-input channels

C300 IntegrationProvide voted speed and status information to the Honeywell C300 controller

Redundant ProtectionDeploy redundant SPM arrangements where the application requires higher availability
