Bently Nevada 991-06-70-02-05 Two-Wire Loop-Powered Thrust Transmitter

991 · THRUST TRANSMITTER

991-06-70-02-05

The 991-06-70-02-05 is a two-wire, loop-powered thrust transmitter with a ±0.6 mm full-scale range, 7.0 m 3300 NSv system length, bulkhead mounting and 4 to 20 mA output.

OUTPUT4-20 mA

MOUNTBulkhead

SYSTEM LENGTH70 · 7.0 m

APPROVALSMultiple

MANUFACTURERBently Nevada · Baker Hughes

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

BENTLY NEVADA ● THRUST TRANSMITTER

991 THRUST TRANSMITTER

991-06-70-02-05

4 TO 20 mA · LOOP POWERED

Two-Wire Axial Displacement Transmitter

MEASUREMENT ROLE

991-06-70-02-05 is a two-wire, loop-powered transmitter that converts 3300 NSv axial-position input into a proportional 4 to 20 mA control signal.

CONFIGURATION NOTE

For 991-06-70-02-05, the official ordering table identifies code 06 as a ±0.6 mm full-scale range, 70 as a 7.0 m system length, 02 as bulkhead-screw mounting, and 05 as multiple approvals including CSA, ATEX and ABS maritime approval.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

CONFIGURATION DECODING

What is confirmed—and what requires verification

991

Base modelTwo-wire
loop powered

Full-scale range

System length

MountingBulkhead screws

ApprovalsCSA / ATEX
ABS maritime

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

991 Transmitter ↗

991 TRANSMITTER

Engineering data at a glance

Click “+” to expand more specifications.

OUTPUT4-20 mA

FULL-SCALE±0.6 MM

SYSTEM LENGTH7.0 M

MOUNTINGBULKHEAD

Official Bently Nevada product data.

Exact configuration verification Verify the complete order number and compatible 3300 NSv probe and extension-cable components against the official datasheet for 991-06-70-02-05.

General Information −

BrandBently Nevada

Part number991-06-70-02-05

Product type991 Thrust Transmitter

Product family991 Thrust Transmitter System

Mounting optionBulkhead screws

Compatible input3300 NSv probe and extension cable

Detailed Measurement Data ＋

Full-scale range±0.6 mm axial displacement

Signal output4 to 20 mAdc, two-wire loop

Power input+12 to +35 Vdc at the transmitter

Cable and Installation ＋

Full-scale code 06±0.6 mm

System length code 707.0 m

Mounting code 02Bulkhead screws

Approval code 05CSA Division 2, ATEX Zone 0/2 and ABS maritime approval

Transmitter typeTwo-wire, loop-powered, potted construction

Environment and Certification ＋

Environmental ratings and certification status depend on the complete probe, extension cable and Proximitor Sensor configuration. Verify 991-06-70-02-05 against the current official manufacturer documentation.

Source: Bently Nevada 991 Thrust Transmitter System, Document 141618. System-level values apply under the manufacturer’s stated test conditions.

FAQ

Questions Buyers Ask Most

What is 991-06-70-02-05 used for?＋

991-06-70-02-05 provides a proportional 4 to 20 mA axial-displacement signal for centrifugal compressors, pumps, motors and fans.

What do the ordering codes in 991-06-70-02-05 mean?＋

For 991-06-70-02-05, code 06 specifies ±0.6 mm full scale, 70 specifies a 7.0 m system, code 02 specifies bulkhead mounting and code 05 specifies multiple approvals.

What signal and power does 991-06-70-02-05 use?＋

991-06-70-02-05 provides a 4 to 20 mA two-wire output and requires +12 to +35 Vdc at the transmitter terminals.

What transducer connects to 991-06-70-02-05?＋

991-06-70-02-05 accepts one compatible 3300 NSv proximity probe and matching extension cable with a 7.0 m system length.

What quotation details are needed for 991-06-70-02-05?＋

For 991-06-70-02-05, provide the transmitter nameplate, 3300 NSv probe and extension-cable part numbers, required range, loop supply, mounting, quantity and destination.

CONTACT PRODUCT SPECIALIST

Check your configuration with Frida

Share the complete label and system details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
991-06-70-02-05

Manufacturer documentation for the Bently Nevada 991 Thrust Transmitter.

991 Thrust Transmitter

Bently Nevada datasheet 141618. Refer to the official 991 ordering information, electrical specifications and 3300 NSv transducer compatibility requirements.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are limited to publicly available Bently Nevada / Baker Hughes manufacturer documentation. No third-party product sources were used.

991 THRUST LOOP RELATIONSHIP

How 991-06-70-02-05 Fits into a 3300 NSv Thrust Measurement Loop

Bently Nevada is the brand; the 991 Thrust Transmitter is the signal-conditioning device; and 991-06-70-02-05 is the ±0.6 mm, 7.0 m, bulkhead-mount configuration.

Bently Nevada · BRAND

991 Thrust TransmitterTRANSMITTER OUTPUT · 4-20 mA

SENSING INPUT

3300 NSv Probe

The compatible 3300 NSv probe senses axial shaft position for the 991-06-70-02-05 transmitter input.

INTERCONNECTION

3300 NSv Extension Cable

The matching extension cable completes the specified 7.0 m probe system length.

TRANSMITTER OUTPUT

991-06-70-02-05

The 991-06-70-02-05 converts axial position into a 4 to 20 mA signal for machinery control and protection logic.

System relationship: a compatible 3300 NSv probe and extension cable feed the 991-06-70-02-05; the probe system length must total 7.0 m.

APPLICATION AREAS

Application map for the 991 Thrust Transmitter

Axial DisplacementProportional thrust-position measurement

OEM Control Input4 to 20 mA input for compressor or pump controls

APPLICATION CENTER 991 Thrust Transmitter Two-wire loop-powered signal conditioning

Protection LogicAlarm and trip logic in the receiving control system

DiagnosticsPROX OUT and gap-voltage diagnostic access
