Bently Nevada 88149-01 3300 Internal Safety Barrier

3300 SYSTEM · INTERNAL SAFETY BARRIER

88149-01

88149-01 — a Bently Nevada two-channel internal zener barrier for approved transducer circuits in the 3300 Monitoring System.

PRODUCTSafety barrier

CHANNELSTwo channels

SYSTEM3300 rack

ROLEIntrinsic safety

MANUFACTURERBently Nevada · Baker Hughes

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

BENTLY NEVADA ● 3300 INTERNAL SAFETY BARRIER

3300 MONITORING SYSTEM

88149-01

Two-channel internal zener barrier

3300 Internal Safety Barrier

INTERNAL BARRIER FUNCTION

88149-01 — A Bently Nevada 3300 internal zener barrier that provides intrinsically safe connections for specified transducer circuits in hazardous areas.

MODEL IDENTITY

Bently Nevada identifies 88149-01 as a 3300 internal barrier in installation manual 88837-01; the applicable wiring diagram is 88839.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

Bently Nevada Official Site ↗

3300 INTERNAL ZENER BARRIER

Engineering data at a glance

Click “+” to expand more specifications.

PRODUCTZener barrier

CHANNELSTwo channels

SYSTEM3300 rack

FUNCTIONIntrinsic safety

Internal zener barrier for specified 3300 transducer circuits.

Barrier integrationThe barrier is built into the 3300 monitor rack and inserted in the transducer lines.

General Information −

BrandBently Nevada

Part number88149-01

Product typeInternal Safety Barrier

Monitoring system3300 Monitoring System

Barrier channelsTwo channels

Barrier technologyZener barrier assembly

Installation locationInside 3300 monitor rack

Field connectionSpecified hazardous-area transducer circuits

Transducer common pathBarrier earth busbar to system common via backplane

Barrier wiring diagram88839 for 88149-01

Source: Bently Nevada 3300 Internal Barriers Installation Manual 88837-01 (Rev G, February 1997).
