/AI-Tek Instruments 70085-1010-412 Passive Variable-Reluctance Speed Sensor

AI-Tek Instruments 70085-1010-412 Passive Variable-Reluctance Speed Sensor

70085 SERIES · PASSIVE SPEED SENSOR

70085-1010-412

The 70085-1010-412 is an AI-Tek Instruments 70085 Series passive variable-reluctance speed sensor with wire termination.

THREAD5/8-18

OUTPUT13.4 V (P-P)

THREAD LENGTH6 in

TERMINATIONWires

MANUFACTURERAI-Tek Instruments

CONDITION / WARRANTYOriginal New · One-Year Warranty

ISO CERTIFICATIONISO-Certified Product

VERIFICATION● Product photos and videos provided after inquiry

REQUEST A QUOTE

✉ EMAIL · sales5@mooreplc.com WHATSAPP · +86 153 5940 8275

Inquire Now

MODEL SEARCHFind a specific part numberOpen the best-matched Moore Automation product page directly.

AI-TEK INSTRUMENTS ● CUSTOMIZED VERSION

AI-TEK 70085 SERIES PASSIVE SPEED SENSOR

70085-1010-412

Passive Variable-Reluctance Speed Sensor

MEASUREMENT ROLE

70085-1010-412 is a passive variable-reluctance speed sensor in the AI-Tek Instruments 70085 Series. The manufacturer describes passive magnetic sensors as self-powered devices with no moving contacts.

CONFIGURATION NOTE

The AI-Tek Passive Sensor Selection Guide lists 70085-1010-412 with 5/8-18 thread, 13.4 V (P-P) guarantee output, wire termination, 6 in thread length and 7.25 in sensor length.

👩‍💼

WANT THE BEST PRICE?

Frida

Sales Leader 🏆

EMAILsales5@mooreplc.com WHATSAPP+86 153 5940 8275

CONFIGURATION DECODING

Manufacturer-listed configuration

70085-1010-412

Base model70085 Series
Passive VR sensor

13.4 V

Output guarantee

-65 to 95°C

Temperature

Wires

TerminationWire leads

6 in

Thread lengthThreaded
length

7.25 in

Sensor length7.25 in

5/8-18

Mounting threadPublished thread size

MANUFACTURER-REFERENCE CHARACTERISTICS

Technical Specifications

AI-Tek 70085 Series ↗

AI-TEK 70085 SERIES

Engineering data at a glance

Click “+” to expand more specifications.

OUTPUTTHREAD
5/8-18

OUTPUTTYPE
Passive VR

SENSOR LENGTH7.25 in

TEMPERATURE-65 to 95°C

AI-Tek Passive Sensor Selection Guide values.

Selection verification Confirm target material, air gap, operating speed, load impedance and installation dimensions before replacement.

General Information −

BrandAI-Tek Instruments

Part number70085-1010-412

Product typePassive Variable-Reluctance Speed Sensor

Product family70085 Series Passive (VR) Speed Sensors

TerminationWire leads

Manufacturer-Listed Data ＋

Thread size5/8-18

Output guarantee13.4 V (P-P)

Output test condition0.030 in gap at 500 IPS

Operating temperature-65 to 95°C

Dimensions and Installation ＋

Thread length6 in

Overall sensor length7.25 in

TerminationWires

Installation checkVerify target, air gap and mounting geometry

Environment and Certification ＋

The official AI-Tek selection guide lists an operating temperature range of -65 to 95°C for 70085-1010-412. Confirm environmental and agency requirements for the complete installation.

Source: AI-Tek Instruments Passive Sensor Selection Guide. Output guarantee is based on the manufacturer’s stated test condition of a 0.030 in gap at 500 IPS.

FAQ

Questions Buyers Ask Most

What is 70085-1010-412 used for?＋

70085-1010-412 is a passive variable-reluctance speed sensor used with a moving ferrous target in speed-sensing, control and protection applications.

What thread and termination does 70085-1010-412 use?＋

70085-1010-412 uses a 5/8-18 thread and wire termination according to the official selection guide.

What dimensions are listed for 70085-1010-412?＋

70085-1010-412 has a 6 in thread length and a 7.25 in overall sensor length.

Does 70085-1010-412 require external sensor power?＋

70085-1010-412 is a passive magnetic sensor; AI-Tek describes this sensor type as self-powered.

What should I provide for a quotation?＋

For 70085-1010-412, send the complete part number, quantity, target details, operating speed, air gap, destination and installation photos.

CONTACT PRODUCT SPECIALIST

Check 70085-1010-412 with Frida

Share the complete sensor and application details for compatibility, availability and lead-time checking.

CHOOSE A DIRECT CONTACT METHOD

sales5@mooreplc.com +86 153 5940 8275

DATA SHEET

Manuals and Official References for
70085-1010-412

Manufacturer documentation for the AI-Tek Instruments 70085 Series Passive (VR) Speed Sensors.

70085 Series Passive (VR) Speed Sensors

AI-Tek Instruments datasheet Passive Sensor Selection Guide. The official guide lists thread, output, termination, length and operating-temperature data for 70085-1010-412.

OFFICIAL DATASHEET

Contact to Get Support

Send the complete model, quantity, and your technical or purchasing question.

EMAIL
sales5@mooreplc.com WHATSAPP
+86 153 5940 8275

Technical statements on this product page are limited to publicly available AI-Tek Instruments manufacturer documentation. No third-party product sources were used.

PASSIVE SPEED SENSOR RELATIONSHIP

How 70085-1010-412 Fits into the AI-Tek 70085 Series

AI-Tek Instruments is the manufacturer, the 70085 Series is the passive variable-reluctance speed-sensor family, and 70085-1010-412 is the specific wire-terminated sensor with a 5/8-18 thread.

AI-Tek Instruments · BRAND

70085 SeriesPRODUCT FAMILY · PASSIVE VR SENSOR

SENSOR TECHNOLOGY

Variable Reluctance

The passive magnetic sensor generates output as a ferrous target passes the pole piece.

TERMINATION

Wires

The manufacturer lists wire termination for 70085-1010-412.

OUTPUT GUARANTEE

13.4 V (P-P)

The official guide lists a 13.4 V (P-P) guaranteed output under its stated test condition.

System relationship: compatible component types and total system length must match the AI-Tek Instruments 70085 Series system requirements.

APPLICATION CONTEXT

Application mind map for the 70085 Series Variable Reluctance

Speed DetectionVariable-reluctance sensing from a moving ferrous target

Control and ProtectionPassive speed sensors support control and protection circuits

PRODUCT CENTER 70085 Series Variable Reluctance Passive variable-reluctance speed sensing

SELF-POWERED OPERATIONPassive magnetic sensing requires no external sensor power

SELECTION REQUIREMENTSConfirm target geometry, speed, air gap and load impedance
